I noticed with current mesa master a visual corruption with the game panzers 2. This is a regression to current git on 7.6 branch where it works fine. I tried a bisect but I get many other bugs (compile errors, r300 segfaults, game crashes that are fixed with mesa master) while doing that and I cannot find the bugged commit. However I suspect the bug appeared around the merging of texformat-rework branch. My card: Mesa DRI R300 (RV530 71C5) 20090101 x86/MMX/SSE2 TCL I also attach a screenshot of the problem: note that the white in the image sometime change to red or blue or dark.
Created attachment 31090 [details] Screenshot of corruption
Please compile mesa with --enable-debug option, and attach full app output.
Created attachment 31733 [details] full console output with mesa *7.6* compiled with --enable-debug and with KMS -> it works fine
Created attachment 31734 [details] full console output with mesa *7.7* compiled with --enable-debug and with KMS -> textures are missing/corrupted
OK I tried again commit around the merge of texformat-rework branch, now with KMS (where the crash bug was not reproducible). It's working fine up to the previous commit: http://cgit.freedesktop.org/mesa/mesa/commit/?h=mesa_7_7_branch&id=0ea575d721821262a862ceef010db9b1a8b4a6d9 The following commit is the merge of the texformat-rework branch and here textures are missing/corrupted: http://cgit.freedesktop.org/mesa/mesa/commit/?h=mesa_7_7_branch&id=1f196b786d6bd0c6a5dbdc638574ff716cc3d4de
I'm taking a quick look at the diffs between 0ea575d721821262a862ceef010db9b1a8b4a6d9 and 1f196b786d6bd0c6a5dbdc638574ff716cc3d4de One thing that looks suspicious is the VALID_FORMAT() macro used in the radeon/r200/r300/etc drivers. I have no idea what it's supposed to do, but it depends on the order/value of the MESA_FORMAT_x tokens. That's pretty fragile. The order of the formats may have changed a bit on the texformat-rework branch. Also, the tx_table[] array is indexed with a MESA_FORMAT_x value so it depends on the MESA_FORMAT_x enums never changing (again, fragile). This should probably be converted into a switch/case in a utility function. Maybe one of the radeon developers can look into this.
(In reply to comment #6) > I'm taking a quick look at the diffs between > 0ea575d721821262a862ceef010db9b1a8b4a6d9 and > 1f196b786d6bd0c6a5dbdc638574ff716cc3d4de > > One thing that looks suspicious is the VALID_FORMAT() macro used in the > radeon/r200/r300/etc drivers. I have no idea what it's supposed to do, but it > depends on the order/value of the MESA_FORMAT_x tokens. That's pretty fragile. > The order of the formats may have changed a bit on the texformat-rework > branch. > > Also, the tx_table[] array is indexed with a MESA_FORMAT_x value so it depends > on the MESA_FORMAT_x enums never changing (again, fragile). This should > probably be converted into a switch/case in a utility function. > > Maybe one of the radeon developers can look into this. > I'll look into it.
Created attachment 31756 [details] proposed patch Fabio: Could you try this patch?
> Could you try this patch? It's still the same with the patch.
Can you check current mesa master?
> Can you check current mesa master? The problem persists, tried with both UMS/KMS.
(In reply to comment #11) > > Can you check current mesa master? > > The problem persists, tried with both UMS/KMS. > It works with the 7.7 branch now, however!
(In reply to comment #12) > (In reply to comment #11) > > > Can you check current mesa master? > > > > The problem persists, tried with both UMS/KMS. > > > > It works with the 7.7 branch now, however! > Ah, right. I was meant to tell you to try the 7.7 branch not the master. Can you confirm it's the f1900323ea1 "r300: fix depth textures" commit that fixed it?
> Ah, right. I was meant to tell you to try the 7.7 branch not the master. Can > you confirm it's the f1900323ea1 "r300: fix depth textures" commit that fixed > it? Confirmed. Thanks for all this nice work!
