Created attachment 23624 [details] screenshot of glyph corruption Hi, I am experiencing significant glyph corruption when using the newest versions of X, the kernel and other libraries. The corruption does not immediately occur. I have to be using the system for approximately 15 minutes before I see the first artifacts (typically shearing) and after an hour or so I get the kind of screen that is attached in the screenshot. Environment: anand@eve[~]% uname -a Linux eve 2.6.29-020629rc6-generic #020629rc6 SMP Mon Feb 23 12:53:58 UTC 2009 i686 GNU/Linux This is 2.6.29rc6 as packaged by Ubuntu. anand@eve[~]% dpkg -l | grep xorg ii xorg 1:7.4~5ubuntu13 X.Org X Window System ii xserver-xorg 1:7.4~5ubuntu13 the X.Org X server ii xserver-xorg-core 2:1.6.0-0ubuntu1 Xorg X server - core server ii xserver-xorg-input-evdev 1:2.1.1-1ubuntu3 X.Org X server -- evdev input driver ii xserver-xorg-input-synaptics 0.99.3-2ubuntu3 Synaptics TouchPad driver for X.Org/XFree86 server ii xserver-xorg-video-all 1:7.4~5ubuntu13 the X.Org X server -- output driver metapackage [...] ii xserver-xorg-video-fbdev 1:0.4.0-3 X.Org X server -- fbdev display driver ii xserver-xorg-video-i128 1:1.3.1-2 X.Org X server -- i128 display driver ii xserver-xorg-video-i740 1:1.2.0-2 X.Org X server -- i740 display driver ii xserver-xorg-video-intel 2:2.6.1-1ubuntu4 X.Org X server -- Intel i8xx, i9xx display driver [...] anand@eve[~]% I have an "older" device: anand@eve[~]% lspci 00:00.0 Host bridge: Intel Corporation 82852/82855 GM/GME/PM/GMV Processor to I/O Controller (rev 02) 00:00.1 System peripheral: Intel Corporation 82852/82855 GM/GME/PM/GMV Processor to I/O Controller (rev 02) 00:00.3 System peripheral: Intel Corporation 82852/82855 GM/GME/PM/GMV Processor to I/O Controller (rev 02) 00:02.0 VGA compatible controller: Intel Corporation 82852/855GM Integrated Graphics Device (rev 02) 00:02.1 Display controller: Intel Corporation 82852/855GM Integrated Graphics Device (rev 02) anand@eve[~]% cat /etc/X11/xorg.conf | grep -v "^#" Section "Device" Identifier "Configured Video Device" Option "UseFBDev" "true" Option "AccelMethod" "uxa" EndSection Section "Monitor" Identifier "Configured Monitor" EndSection Section "Screen" Identifier "Default Screen" Monitor "Configured Monitor" Device "Configured Video Device" EndSection
Does this happen without uxa set? Please attach Xorg.0.log.
Created attachment 23690 [details] Xorg.0.log Attached the Xorg.0.log as requested.
Commenting out 'Option "AccelMethod" "uxa"' results in X not being able to startup correctly. I get dumped into Ubuntu 'low-graphics' system. The reason is: (EE) intel(0): Failed ot pin front buffer: Cannot allocate memory. I have attached the Xorg.0.log for when the configuration looks like: anand@eve:~$ grep -v "^#" /etc/X11/xorg.conf Section "Device" Identifier "Configured Video Device" Option "UseFBDev" "true" EndSection Section "Monitor" Identifier "Configured Monitor" EndSection Section "Screen" Identifier "Default Screen" Monitor "Configured Monitor" Device "Configured Video Device" EndSection
Created attachment 23692 [details] Xorg.0.log when uxa is commented out Xorg.0.log when uxa is commented out.
I have similar problem on i945G. After some time I get blurry squares instead of some letters in my terminals (rxvt-unicode, truetype fonts). The corruption is not limited to a particular terminal, all terminals seem to be affected in the same way, and they are separate processes (not the hydra-like server process). I am running UXA as XAA crashes on startup and EXA tends to lock up on this hardware.
Created attachment 26529 [details] glyph-cache.png The same happens with UXA on my "Intel Corporation Mobile GM965/GL960 Integrated Graphics Controller (rev 0c)" with xf86-video-intel 2.7.1, mesa 7.5_rc3, libdrm 2.4.11 and X.org 1.6.1.901. It seems to happen often with lasge subpixel hinted fonts, something like 14-16 pt, but only at that specific size. Larger and smaller fonts are not affected (at least for me).
One addition: Italic text more commonly seems to trigger the issue.
To me this seems like a general pixmap corruption that is more likely to manifest on fonts. For some reason fonts used in gkrellm are not affected - perhaps they are rendered in different way than what Firefox and urxvt. does. Uncommon font sizes (like very large or very small) are probably not affected because they are not chaced and have to be freshly re-rendered. In one case I was able to completely clear the terminal corruption by invoking the visual bell feature. It is not only fonts what is corrupted. Sometimes images in Firefox (both HTML and XUL) or the xscreensaver logo would get corrupted by horizontal lines in toolkit background color or some garbage. The letters in the affected fonts sometimes seem incomplete or partially replaced by something different, sometimes replaced completely with garbage or a letter from a different font.
I have to agree. Some icons in eclipse were corrupted, too. So it's not limited to font glyphs.
Updating summary accordingly.
This should have been fixed by: commit 07f4f3e8a24138ca2f3650723d670df25687cd05 Author: Kristian Høgsberg <krh@redhat.com> Date: Wed May 27 14:37:28 2009 -0400 i915: Set object to gtt domain when faulting it back in in 2.6.30. Please reopen if retesting with 2.6.30 release continues to show this bug.
