The World of Warcraft login screen (with the flying dragon) looks like a cubist nightmare for me... the dragon is inside out and all of the text boxes/buttons are also scrambled. From this I infer that both 3D and 2D are badly screwed up. This bug occurs for me when trying to run/install WoW in either Wine or CrossOver. My system looks like this: Intel Core 2 duo E7500 processor Intel motherboard DG43NB which has built-in graphics chip GMA-X4500 4GB DDR2 memory I have hit this problem through the following combinations of installs: 1. Install Ubuntu 9.10 in *either* the 32-bit *or* 64-bit version. 2. Patch Ubuntu to get up to date. 3. Install the wine dependencies from winehq (install-wine-deps.sh) 4. Install ubuntu-restricted-extras and msttcorefonts 5. Install *either* Wine (latest version in the Ubuntu repository) *or* CrossOver (latest version 8.0.0). 6. Install World of Warcraft and Burning Crusade through Wine/CrossOver, and then let the program patch itself up to the current version. Ok, so I'm talking about 4 combinations here (32/64 and Wine/CrossOver). None of them have worked for me. However I did have working 2D textboxes/text-input and buttons on the 32-bit Ubuntu installation. I cannot reproduce these just at the moment because the latest WoW patch has also introduced new login errors for Wine/CrossOver users (different bug/issue). Thanks to everyone out there who's working on Mesa/DRI/OpenGL/whatever! Cheers, Nat
Created attachment 31161 [details] WoW login screen due to bug, 64-bit Ubuntu install
Just a headsup -- while this is assigned to me, I won't be making progress on it (except accidentally while fixing other issues) unless we can isolate some minimal testcases for what WoW is doing.
Hi, I experience the same bug, after installing wow WoLK and seeing the intro, it all look messed up. uname -a: Linux Ejdesgaard 2.6.31-gentoo-r6 #3 SMP Sat Nov 28 13:31:55 WET 2009 x86_64 AMD Phenom(tm) II X4 965 Processor AuthenticAMD GNU/Linux lspci: 00:00.0 Host bridge: Advanced Micro Devices [AMD] RS780 Host Bridge 00:01.0 PCI bridge: Advanced Micro Devices [AMD] RS780 PCI to PCI bridge (int gfx) 00:06.0 PCI bridge: Advanced Micro Devices [AMD] RS780 PCI to PCI bridge (PCIE port 2) 00:07.0 PCI bridge: Advanced Micro Devices [AMD] RS780 PCI to PCI bridge (PCIE port 3) 00:11.0 SATA controller: ATI Technologies Inc SB700/SB800 SATA Controller [IDE mode] 00:12.0 USB Controller: ATI Technologies Inc SB700/SB800 USB OHCI0 Controller 00:12.1 USB Controller: ATI Technologies Inc SB700 USB OHCI1 Controller 00:12.2 USB Controller: ATI Technologies Inc SB700/SB800 USB EHCI Controller 00:13.0 USB Controller: ATI Technologies Inc SB700/SB800 USB OHCI0 Controller 00:13.1 USB Controller: ATI Technologies Inc SB700 USB OHCI1 Controller 00:13.2 USB Controller: ATI Technologies Inc SB700/SB800 USB EHCI Controller 00:14.0 SMBus: ATI Technologies Inc SBx00 SMBus Controller (rev 3c) 00:14.1 IDE interface: ATI Technologies Inc SB700/SB800 IDE Controller 00:14.2 Audio device: ATI Technologies Inc SBx00 Azalia (Intel HDA) 00:14.3 ISA bridge: ATI Technologies Inc SB700/SB800 LPC host controller 00:14.4 PCI bridge: ATI Technologies Inc SBx00 PCI to PCI Bridge 00:14.5 USB Controller: ATI Technologies Inc SB700/SB800 USB OHCI2 Controller 00:18.0 Host bridge: Advanced Micro Devices [AMD] Family 10h [Opteron, Athlon64, Sempron] HyperTransport Configuration 00:18.1 Host bridge: Advanced Micro Devices [AMD] Family 10h [Opteron, Athlon64, Sempron] Address Map 00:18.2 Host bridge: Advanced Micro Devices [AMD] Family 10h [Opteron, Athlon64, Sempron] DRAM Controller 00:18.3 Host bridge: Advanced Micro Devices [AMD] Family 10h [Opteron, Athlon64, Sempron] Miscellaneous Control 00:18.4 Host bridge: Advanced Micro Devices [AMD] Family 10h [Opteron, Athlon64, Sempron] Link Control 01:05.0 VGA compatible controller: ATI Technologies Inc Radeon HD 3300 Graphics 01:05.1 Audio device: ATI Technologies Inc RS780 Azalia controller 02:00.0 Ethernet controller: Attansic Technology Corp. L1 Gigabit Ethernet Adapter (rev b0) 03:00.0 FireWire (IEEE 1394): VIA Technologies, Inc. Device 3403 Drivers etc: x11-drivers/xf86-video-radeonhd-1.2.5 media-libs/mesa-7.5.1 Crossover info: Product Name: CrossOver Games Public Version: 8.1.3 Product Version: 8.1.3 Build Tag: cxgames-8.1.3rc1 Build Timestamp: 20091124T221922Z
Created attachment 31536 [details] glxinfo
Created attachment 31537 [details] screenshot of the problem
Heðin, you don't even have intel hardware. You need to open your own bug report for your own issue.
OK, with various fixes to handling of large numbers of constants on Mesa master, it looks like wow rendering now pretty much works, and the remaining rendering error I can see from launch through character creation and login is on textures for terrain nearly parallel to the eye vector. That'll be a different bug from this one.
