Bug 25366 - PGRAPH_ERROR with Quadro NVS 280 SD (NV17 or NV18)
Summary: PGRAPH_ERROR with Quadro NVS 280 SD (NV17 or NV18)
Alias: None
Product: xorg
Classification: Unclassified
Component: Driver/nouveau (show other bugs)
Version: 7.5 (2009.10)
Hardware: x86 (IA32) Linux (All)
: medium normal
Assignee: Nouveau Project
QA Contact: Xorg Project Team
: 27153 (view as bug list)
Depends on:
Reported: 2009-11-30 09:05 UTC by Pawel Moll
Modified: 2010-09-07 17:56 UTC (History)
1 user (show)

See Also:
i915 platform:
i915 features:

That's how my desktop looks like after 10-15 minutes... (548.47 KB, image/png)
2009-11-30 09:05 UTC, Pawel Moll
no flags Details
Kernel log from init to first errors... (37.65 KB, text/plain)
2009-11-30 09:06 UTC, Pawel Moll
no flags Details

Description Pawel Moll 2009-11-30 09:05:11 UTC
I've upgraded to Fedora 12 recently... As the binary drivers for my old old old card (nvidia_96xx) are not supported yet (or maybe any more ;-) I've decided to give nouveau a try.

It starts like a charm, but shortly after (a few minutes) everything goes bunkers - fonts instead of being black are light grey or pink ;-), bitmaps are corrupted. In a second I'll attach a screenshot of my screen after about 10-15 minutes.

The kernel (log to be attached as well) is screaming like this:

[drm] nouveau 0000:01:00.0: PGRAPH_ERROR - nSource: PROTECTION_ERROR, nStatus: INVALID_STATE
[drm] nouveau 0000:01:00.0: PGRAPH_ERROR - Ch 1/0 Class 0x0039 Mthd 0x0184 Data 0x000011ce:0x000011ce

My system:

$ X -version

X.Org X Server 1.7.1
Release Date: 2009-10-23
X Protocol Version 11, Revision 0
Build Operating System:  2.6.18-164.2.1.el5
Current Operating System: Linux sedan #1 SMP Sat Nov 7 21:25:57 EST 2009 i686
Kernel command line: ro root=LABEL=/ rhgb quiet SYSFONT=latarcyrheb-sun16 LANG=en_GB.UTF-8 KEYTABLE=pl2
Build Date: 05 November 2009  07:43:20PM
Build ID: xorg-x11-server 1.7.1-7.fc12
Current version of pixman: 0.16.2
	Before reporting problems, check http://bodhi.fedoraproject.org/
	to make sure that you have the latest version.

The card:

01:00.0 VGA compatible controller: nVidia Corporation NV18GL [Quadro NVS 280 SD] (rev a2) (prog-if 00 [VGA controller])
	Subsystem: nVidia Corporation Device 0190
	Control: I/O+ Mem+ BusMaster- SpecCycle- MemWINV- VGASnoop- ParErr- Stepping- SERR- FastB2B- DisINTx-
	Status: Cap+ 66MHz+ UDF- FastB2B+ ParErr- DEVSEL=medium >TAbort- <TAbort- <MAbort- >SERR- <PERR- INTx-
	Interrupt: pin A routed to IRQ 11
	Region 0: Memory at fc000000 (32-bit, non-prefetchable) [size=16M]
	Region 1: Memory at f0000000 (32-bit, prefetchable) [size=128M]
	Expansion ROM at fd000000 [disabled] [size=128K]
	Capabilities: <access denied>
	Kernel modules: nouveau, nvidiafb

As you see lspci claims it's NV18-base card, while the driver says:

[drm] nouveau 0000:01:00.0: Detected an NV17 generation card (0x018a00a3)

Any other data I can provide?
Comment 1 Pawel Moll 2009-11-30 09:05:57 UTC
Created attachment 31600 [details]
That's how my desktop looks like after 10-15 minutes...
Comment 2 Pawel Moll 2009-11-30 09:06:21 UTC
Created attachment 31601 [details]
Kernel log from init to first errors...
Comment 3 Francisco Jerez 2010-09-07 17:54:08 UTC
*** Bug 27153 has been marked as a duplicate of this bug. ***
Comment 4 Francisco Jerez 2010-09-07 17:56:26 UTC
This should be fixed with latest git, please reopen if it's not.
