Bug 29469 - [r600g] tiling breaks rendering
Summary: [r600g] tiling breaks rendering
Alias: None
Product: DRI
Classification: Unclassified
Component: DRM/Radeon (show other bugs)
Version: XOrg git
Hardware: x86-64 (AMD64) Linux (All)
: medium normal
Assignee: Default DRI bug account
QA Contact:
Depends on:
Reported: 2010-08-09 15:41 UTC by Tobias Jakobi
Modified: 2010-09-20 09:28 UTC (History)
1 user (show)

See Also:
i915 platform:
i915 features:

glxgears screenshot (18.72 KB, image/png)
2010-09-20 04:26 UTC, Nicolas Kaiser
no flags Details

Description Tobias Jakobi 2010-08-09 15:41:38 UTC
Hi there,

just recently the tiling patches for r6xx went into git master. I noticed that r600c works fine with these, but r600g breaks with ColorTiling enabled. To get correct visuals out of the gallium driver I have to disable tiling first, then it works again.

Seems like r600g misinterprets the tiling state of the framebuffer. The visuals are similar to the ones you got when patching mesa with the tiling patchset, but forgetting to do the same for the ddx.

Comment 1 Nicolas Kaiser 2010-09-20 04:26:20 UTC
Created attachment 38811 [details]
glxgears screenshot

I guess I saw the same with recent kernels. Only with r600g, r600c wasn't affected.

Mesa commit 9b146eae2521d8e5f6d3cbefa4f6f7737666313a (Dave Airlie)
"r600g: fix tiling support for ddx supplied buffers"
fixed it at my place.

FWIW, I bisected to kernel commit:
e7aeeba6a8fb86ac52bcffa0b72942f784f2b37f (Alex Deucher)
"drm/radeon/kms/r6xx+: add query for tile config (v2)"

System environment:
-- system architecture: amd64
-- Linux distribution: Gentoo
-- GPU: RS780G
-- Model: ATI Radeon HD 3200
-- Display connector: VGA
-- xf86-video-ati: b90cb61ccb0f4f80e0627141f223354a9371d47d
-- xserver: 1.9.0
-- mesa: fd266ec62ca772a8551d2d7922d718d9d84bdf07
-- drm: 7ec9a1effa4f551897f91f3b017723a8adf011d9
-- kernel: bisected to e7aeeba6a8fb86ac52bcffa0b72942f784f2b37f
Comment 2 Jerome Glisse 2010-09-20 09:28:45 UTC
