Created attachment 42592 [details] screenshot showing the issue I have two machines: The first one is a tower machine with a NVIDIA graphics card (GeForce 6200) where all my users and applications are set up and XDMCP is enabled: - set Enable=true in the [Xdmcp] section of /etc/kde4/kdm/kdmrc - uncomment the following line in /etc/kde4/kdm/Xaccess #* #any host can get a login window The second machine is a Dell Optiplex SX280, serving as a thin client: - disable kdm (mv /etc/init/kdm.conf /etc/init/kdm.conf.not) - create /etc/init/thinclient.conf as follows: ---------------- start on net-device-up stop on runlevel [016] exec X -broadcast ---------------- Some info about the graphics board of my Dell Optiplex: lspci: 00:02.0 VGA compatible controller: Intel Corporation 82915G/GV/910GL Integrated Graphics Controller (rev 04) lspci -n: 00:02.0 0300: 8086:2582 (rev 04) When I log in at the thin client, everything is upside down (see attachment). Only if I disable desktop effects, the issue is not triggered.
Can you also switch between 'xrender' and 'gl' based desktop effects and see if the problem persists?
Indeed, the problem does not show up when using xrender based desktop effects.
A continuation of bug 24084?
(In reply to comment #3) > A continuation of bug 24084? I don't really know, I am just a mortal user, no developer, but the issue looks very similar.
Created attachment 44039 [details] [review] Patch from Henri Verbeet that may fix the issue. Henri Verbeet recently sent a patch to the mailing list that looks like it may fix this issue. Could you please test it?
> Could you please test it? Unfortunately, I currently lack both the skills and time to test this patch. I don't even know where to start... But I am motivated to help. Do you have simple step-by-step instructions how to test this patch?
I have exactly the same problem with slightly different hardware. If I use the 'intel' driver with out composite then the graphics is OK. Enabling composite, i.e. Option "Composite" "enable", results in the upside down mirrored behavior, except for the positioning of the panel at the bottom of the display, see "xorg.conf". My system is installed with openSUSE 11.4 and uses a i5-2500K CPU with HD 3000 graphics. my_srv:~ # lspci -n 00:00.0 0600: 8086:0100 (rev 09) 00:02.0 0300: 8086:0112 (rev 09) ... my_srv:~ # lspci 00:00.0 Host bridge: Intel Corporation 2nd Generation Core Processor Family DRAM Controller (rev 09) 00:02.0 VGA compatible controller: Intel Corporation 2nd Generation Core Processor Family Integrated Graphics Controller (rev 09) ... Currently I have installed kernel 2.6.39, with Mesa 7.10.2. Some packages from Tumbleweed and X11:XOrg repository. Full package list and the repositories is given in "pkg_list.gz". Linux my_srv 2.6.39-30-desktop #1 SMP PREEMPT Fri May 20 18:23:02 UTC 2011 (a64b7f7) x86_64 x86_64 x86_64 GNU/Linux To test the patch I have updated the rpm for Mesa and included the patch, see "Mesa.spec.diff" and "Mesa.spec". After I installed the package unfortunately the problem was not resolved.
Created attachment 47221 [details] spec file for Mesa
Created attachment 47222 [details] [review] changes to original spec file
Created attachment 47223 [details] my installed packages 'pkg_list.gz'
Created attachment 47224 [details] Xorg.0.log file with applied patch
Created attachment 47225 [details] 'xorg.conf' file used to test patch
With Mesa 7.10.3, 915GM hardware, I just installed kde 4.6.4 or so from Debian, started X with "startkde", desktop effects were enabled by default, and everything is right side up. Note that 7.10.3 doesn't have Henri's patch. I'm going to need some more details on how to reproduce the issue.
Comment on attachment 44039 [details] [review] Patch from Henri Verbeet that may fix the issue. frederikh says that 4.6 doesn't use gl_FragCoord except for the "snow" effect, so it's not going to be this patch. Still don't know how to reproduce the problem.
The problem is now solved for me too. The problem was left over libraries from a Nvidia driver installation. I detected that cause when I typed mach@user > glxinfo name of display: :0 Xlib: extension "NV-GLX" missing on display ":0". display: :0 screen: 0 direct rendering: No server glx vendor string: SGI server glx version string: 1.4 server glx extensions: GLX_ARB_multisample, GLX_EXT_import_context, GLX_EXT_texture_from_pixmap, GLX_EXT_visual_info, GLX_EXT_visual_rating, GLX_MESA_copy_sub_buffer, GLX_OML_swap_method, GLX_SGI_make_current_read, GLX_SGI_swap_control, GLX_SGIS_multisample, GLX_SGIX_fbconfig, GLX_SGIX_pbuffer, GLX_SGIX_visual_select_group, GLX_INTEL_swap_event client glx vendor string: NVIDIA Corporation client glx version string: 1.4 client glx extensions: GLX_ARB_get_proc_address, GLX_ARB_multisample, GLX_EXT_visual_info, GLX_EXT_visual_rating, GLX_EXT_import_context, GLX_SGI_video_sync, GLX_NV_swap_group, GLX_NV_video_out, GLX_SGIX_fbconfig, GLX_SGIX_pbuffer, GLX_SGI_swap_control, GLX_EXT_swap_control, GLX_ARB_create_context, GLX_ARB_create_context_profile, GLX_NV_float_buffer, GLX_ARB_fbconfig_float, GLX_EXT_fbconfig_packed_float, GLX_EXT_texture_from_pixmap, GLX_EXT_framebuffer_sRGB, GLX_NV_present_video, GLX_NV_copy_image, GLX_NV_multisample_coverage, GLX_NV_video_capture, GLX_EXT_create_context_es2_profile, GLX_ARB_create_context_robustness GLX extensions: GLX_ARB_multisample, GLX_EXT_import_context, GLX_EXT_texture_from_pixmap, GLX_EXT_visual_info, GLX_EXT_visual_rating, GLX_SGI_swap_control, GLX_SGIX_fbconfig, GLX_SGIX_pbuffer, GLX_ARB_get_proc_address OpenGL vendor string: Tungsten Graphics, Inc OpenGL renderer string: Mesa DRI Intel(R) Sandybridge Desktop OpenGL version string: 1.4 (2.1 Mesa 7.10.3) OpenGL extensions: GL_ARB_depth_texture, GL_ARB_draw_buffers, GL_ARB_fragment_program, GL_ARB_fragment_program_shadow, GL_ARB_multisample, GL_ARB_multitexture, GL_ARB_occlusion_query, GL_ARB_point_parameters, GL_ARB_point_sprite, GL_ARB_shadow, GL_ARB_texture_border_clamp, GL_ARB_texture_compression, GL_ARB_texture_cube_map, GL_ARB_texture_env_add, GL_ARB_texture_env_combine, GL_ARB_texture_env_crossbar, GL_ARB_texture_env_dot3, GL_ARB_texture_mirrored_repeat, GL_ARB_texture_non_power_of_two, GL_ARB_transpose_matrix, GL_ARB_vertex_program, GL_ARB_window_pos, GL_EXT_abgr, GL_EXT_bgra, GL_EXT_blend_color, GL_EXT_blend_func_separate, GL_EXT_blend_minmax, GL_EXT_blend_subtract, GL_EXT_draw_range_elements, GL_EXT_fog_coord, GL_EXT_framebuffer_object, GL_EXT_multi_draw_arrays, GL_EXT_packed_pixels, GL_EXT_point_parameters, GL_EXT_rescale_normal, GL_EXT_secondary_color, GL_EXT_separate_specular_color, GL_EXT_shadow_funcs, GL_EXT_stencil_two_side, GL_EXT_stencil_wrap, GL_EXT_texture3D, GL_EXT_texture_edge_clamp, GL_EXT_texture_env_add, GL_EXT_texture_env_combine, GL_EXT_texture_env_dot3, GL_EXT_texture_filter_anisotropic, GL_EXT_texture_lod_bias, GL_EXT_texture_object, GL_EXT_vertex_array, GL_IBM_texture_mirrored_repeat, GL_NV_blend_square, GL_NV_depth_clamp, GL_NV_light_max_exponent, GL_NV_texgen_reflection, GL_NV_texture_env_combine4, GL_NV_texture_rectangle, GL_NV_vertex_program1_1, GL_NV_vertex_program, GL_SGIS_generate_mipmap, GL_SGIS_texture_lod glu version: 1.3 glu extensions: GLU_EXT_nurbs_tessellator, GLU_EXT_object_space_tess *** *** WARNING: Direct Rendering is NOT enabled *** visual x bf lv rg d st colorbuffer ax dp st accumbuffer ms cav id dep cl sp sz l ci b ro r g b a bf th cl r g b a ns b eat ---------------------------------------------------------------------- 0x21 24 tc 0 32 0 r y . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0x22 24 dc 0 32 0 r y . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0x90 24 tc 0 24 0 r . . 8 8 8 0 0 0 0 0 0 0 0 0 0 None 0x91 24 tc 0 24 0 r y . 8 8 8 0 0 0 0 0 0 0 0 0 0 None 0x92 24 tc 0 24 0 r y . 8 8 8 0 0 0 0 0 0 0 0 0 0 None 0x93 24 tc 0 24 0 r . . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0x94 24 tc 0 24 0 r y . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0x95 24 tc 0 24 0 r y . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0x96 24 tc 0 32 0 r . . 8 8 8 8 0 0 0 0 0 0 0 0 0 None 0x97 24 tc 0 32 0 r y . 8 8 8 8 0 0 0 0 0 0 0 0 0 None 0x98 24 tc 0 32 0 r y . 8 8 8 8 0 0 0 0 0 0 0 0 0 None 0x99 24 tc 0 32 0 r . . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0x9a 24 tc 0 32 0 r y . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0x9b 24 tc 0 24 0 r y . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0x9c 24 tc 0 24 0 r y . 8 8 8 0 0 24 8 16 16 16 0 0 0 Slow 0x9d 24 tc 0 32 0 r y . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0x9e 24 tc 0 32 0 r y . 8 8 8 8 0 24 8 16 16 16 16 0 0 Slow 0x9f 24 dc 0 24 0 r . . 8 8 8 0 0 0 0 0 0 0 0 0 0 None 0xa0 24 dc 0 24 0 r y . 8 8 8 0 0 0 0 0 0 0 0 0 0 None 0xa1 24 dc 0 24 0 r y . 8 8 8 0 0 0 0 0 0 0 0 0 0 None 0xa2 24 dc 0 24 0 r . . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0xa3 24 dc 0 24 0 r y . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0xa4 24 dc 0 24 0 r y . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0xa5 24 dc 0 32 0 r . . 8 8 8 8 0 0 0 0 0 0 0 0 0 None 0xa6 24 dc 0 32 0 r y . 8 8 8 8 0 0 0 0 0 0 0 0 0 None 0xa7 24 dc 0 32 0 r y . 8 8 8 8 0 0 0 0 0 0 0 0 0 None 0xa8 24 dc 0 32 0 r . . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0xa9 24 dc 0 32 0 r y . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0xaa 24 dc 0 24 0 r y . 8 8 8 0 0 24 8 0 0 0 0 0 0 None 0xab 24 dc 0 24 0 r y . 8 8 8 0 0 24 8 16 16 16 0 0 0 Slow 0xac 24 dc 0 32 0 r y . 8 8 8 8 0 24 8 0 0 0 0 0 0 None 0xad 24 dc 0 32 0 r y . 8 8 8 8 0 24 8 16 16 16 16 0 0 Slow [ 1392.041] (WW) intel(0): Option "AllowGLXWithComposite" is not used [ 1392.041] (WW) intel(0): Option "XAANoOffscreenPixmaps" is not used [ 1392.041] (WW) intel(0): Option "AddARGBGLXVisuals" is not used [ 1392.041] (WW) intel(0): Option "DisableGLXRootClipping" is not used name of display: :0 Definitely, "NV-GLX" was wrong. Then I looked at the open files and saw lsof|grep nvidia|sed -e 's@.* \(/.*\)$@\1@'|sort -u lsof|grep 260.19.36|sed -e 's@.* \(/.*\)$@\1@'|sort -u that still the three libraries from a former Nvidia driver installation (version 260.19.36 was the latest Nvidia driver I had installed with the Nvidia install script, not rpm package) was present. I assume that they were loaded instead of the Mesa libGL since they might have appeared first in the paths were the system looked for libraries. /usr/lib64/libnvidia-glcore.so.260.19.36 /usr/lib64/tls/libnvidia-tls.so.260.19.36 /usr/X11R6/lib64/libGL.so.260.19.36 After I removed the directory "/usr/X11R6/lib64" everything is now working for me fine. Thanks for having a look at the problem.
