Bug 71846 - intel-virtual-output: Support for rotated displays
intel-virtual-output: Support for rotated displays
Status: RESOLVED FIXED
Product: xorg
Classification: Unclassified
Component: Driver/intel
git
x86-64 (AMD64) Linux (All)
: medium normal
Assigned To: Chris Wilson
Intel GFX Bugs mailing list
:
Depends on:
Blocks:
  Show dependency treegraph

Reported: 2013-11-20 17:33 UTC by Kirill Müller
Modified: 2013-11-26 10:57 UTC (History)
0 users

See Also:
i915 platform:
i915 features:


Attachments
xrandr -d :0 --verbose (Ubuntu 13.04 system with patched Intel driver) (9.10 KB, text/plain)
2013-11-21 09:28 UTC, Kirill Müller
no flags Details
xrandr -d :8 --verbose (Ubuntu 13.04 system with patched Intel driver) (8.23 KB, text/plain)
2013-11-21 09:28 UTC, Kirill Müller
no flags Details
xrandr -d :0 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b) (10.53 KB, text/plain)
2013-11-21 09:54 UTC, Kirill Müller
no flags Details
xrandr -d :8 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b) (8.00 KB, text/plain)
2013-11-21 09:54 UTC, Kirill Müller
no flags Details
As requested, result of intel-virtual-output -b -f | tee ivo2.txt (1.18 MB, text/plain)
2013-11-25 13:11 UTC, Kirill Müller
no flags Details
As requested, result of inAs requested, result of intel-virtual-output -b -f | tee ivo2.txt tel-virtual-output -b -f | tee ivo3.txt (109.86 KB, text/plain)
2013-11-25 13:25 UTC, Kirill Müller
no flags Details
Another result of intel-virtual-output -b -f | tee ivo4.txt (348.00 KB, text/plain)
2013-11-25 15:14 UTC, Kirill Müller
no flags Details
Xorg.0.log (32.99 KB, text/plain)
2013-11-25 15:15 UTC, Kirill Müller
no flags Details
xrandr -d :0 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b, second try) (10.84 KB, text/plain)
2013-11-25 16:01 UTC, Kirill Müller
no flags Details
xrandr -d :8 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b, second try) (8.01 KB, text/plain)
2013-11-25 16:01 UTC, Kirill Müller
no flags Details
as requested (33.78 KB, text/plain)
2013-11-25 16:27 UTC, Kirill Müller
no flags Details
as requested (10.84 KB, text/plain)
2013-11-25 16:28 UTC, Kirill Müller
no flags Details
as requested (8.01 KB, text/plain)
2013-11-25 16:28 UTC, Kirill Müller
no flags Details
as requested (192.00 KB, text/plain)
2013-11-25 16:29 UTC, Kirill Müller
no flags Details
as usual (44.72 KB, text/plain)
2013-11-26 08:22 UTC, Kirill Müller
no flags Details
as usual (10.85 KB, text/plain)
2013-11-26 08:22 UTC, Kirill Müller
no flags Details
as usual (8.01 KB, text/plain)
2013-11-26 08:22 UTC, Kirill Müller
no flags Details
as usual (500.00 KB, text/plain)
2013-11-26 08:25 UTC, Kirill Müller
no flags Details
Screenshot of (2.74 MB, text/plain)
2013-11-26 08:35 UTC, Kirill Müller
no flags Details
Screen-shot with proper MIME type (2.74 MB, image/png)
2013-11-26 08:37 UTC, Kirill Müller
no flags Details

Note You need to log in before you can comment on or make changes to this bug.
Description Kirill Müller 2013-11-20 17:33:09 UTC
I am testing a tri-head setup on 13.10 with my Lenovo T430 with the new xserver-xorg-video-intel. I have my laptop screen, DP1 right of it, and DP2 right of it -- rotated. This works with puetzk's screenclone, I also need to specify rotation for the second screen of DISPLAY :8 and use a "rotated" mode (1200x1920) for the second virtual screen. (See http://askubuntu.com/a/303897/30266 for more information.)

I wonder if `intel-virtual-output` could be enhanced to support rotated displays.
If possible, I would like to use `intel-virtual-output` instead of `screenclone` because it does all necessary setup. I'll be glad to test a patch before it's applied upstream.

Note that, with the default xserver-xorg-video-intel in Ubuntu 13.10, the virtual screen cannot be rotated using `xrandr --rotate ...`. Using a "rotated" mode (1200x1920) works.
Comment 1 Chris Wilson 2013-11-20 17:45:13 UTC
The code does copy across the rotation from the VIRTUAL to the remote display. Hopefully it is just a trivial bug... What it can't acutally do is back-propagate the limits from the remote display, but that doesn't sound like the issue here.

xrandr -d :0 --verbose
xrandr -d :8 --verbose

would be very useful
Comment 2 Kirill Müller 2013-11-20 17:49:04 UTC
I cannot set rotation for the VIRTUAL display:

    xrandr ... --output VIRTUAL1 --rotate left

throws an error, I can post exact error message tomorrow.

This is with most recent xserver-xorg-video-intel from the Ubuntu repos (no edgers/x-swat).
Comment 3 Kirill Müller 2013-11-21 09:28:21 UTC
Created attachment 89579 [details]
xrandr -d :0 --verbose (Ubuntu 13.04 system with patched Intel driver)
Comment 4 Kirill Müller 2013-11-21 09:28:54 UTC
Created attachment 89580 [details]
xrandr -d :8 --verbose (Ubuntu 13.04 system with patched Intel driver)
Comment 5 Kirill Müller 2013-11-21 09:52:27 UTC
This is what I see when attempting to rotate a virtual display:

$ xrandr --output VIRTUAL5 --rotate left
xrandr: output VIRTUAL5 cannot use rotation "left" reflection "none"
Comment 6 Kirill Müller 2013-11-21 09:54:06 UTC
Created attachment 89581 [details]
xrandr -d :0 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b)
Comment 7 Kirill Müller 2013-11-21 09:54:28 UTC
Created attachment 89582 [details]
xrandr -d :8 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b)
Comment 8 Chris Wilson 2013-11-21 10:09:21 UTC
commit 7d9edc9a717cfc6fbdbe468f7e32a68ac674a207
Author: Chris Wilson <chris@chris-wilson.co.uk>
Date:   Wed Nov 20 18:50:40 2013 +0000

    sna: Set supported rotations on virtual outputs

    As the virtual outputs are created later, they do not get automatically
    populated with RR properties and we must do that instantiation
    ourselves.

    Reported-by: Kirill Müller <mail@kirill-mueller.de>
    Bugzilla: https://bugs.freedesktop.org/show_bug.cgi?id=71846
    Signed-off-by: Chris Wilson <chris@chris-wilson.co.uk>
Comment 9 Kirill Müller 2013-11-22 12:29:16 UTC
Updated to tip of Git.

Rotation now works. When I rotate the third screen (VIRTUAL5), I also have to rotate the corresponding Bumblebee screen (DP-2). When I do this, I see that the desktop area is adapted, but the lower part of the third screen (y >= 1200) is not updated and remains black.

- Any chance to auto-rotate DP-2?
- Hope it's easy to compute the correct update area even in the case of rotation.

Thanks a lot.
Comment 10 Chris Wilson 2013-11-22 13:15:42 UTC
When I did it locally, the rotation was propagated through to the remote display as expected. :|
Comment 11 Kirill Müller 2013-11-22 15:32:09 UTC
Is not on my system, I have checked again. The ivo.txt I have attached to the other ticket is without rotation -- does it make sense to repeat the exercise with rotation, or do you have to add more debugging code up front?
Comment 12 Kirill Müller 2013-11-25 13:11:56 UTC
Created attachment 89746 [details]
As requested, result of intel-virtual-output -b -f | tee ivo2.txt

I did the following:

- Turned off and on the third (=second virtual) display
- Set up rotation for the third display
- Issued `xrandr -d :8 --output DP-2 --rotate left` (because the rotation is still not propagated)
- Moved the cursor to the third display and back (still not shown on the third display, see linked ticket)

Everything seems to work, except for updating a part of the rotated screen (I guess the one below 1200 pixels). Could you check if the routine that copies screen contents respects rotation? To me it looks like it tries to copy 1920x1200 when it should copy 1200x1920.
Comment 13 Kirill Müller 2013-11-25 13:25:06 UTC
Created attachment 89747 [details]
As requested, result of inAs requested, result of intel-virtual-output -b -f | tee ivo2.txt tel-virtual-output -b -f | tee ivo3.txt

Like the previous attachment, but this time really against Git tip. Cursor is shown on third monitor, copying issue persists.
Comment 14 Chris Wilson 2013-11-25 14:32:15 UTC
It is not reporting that VIRTUAL2 is rotated. Can you please attach the current xrandr --verbose? (Make sure that the ddx is also updated, so please also attach the Xorg.0.log.)
Comment 15 Kirill Müller 2013-11-25 15:14:42 UTC
Created attachment 89757 [details]
Another result of intel-virtual-output -b -f | tee ivo4.txt

Another run. Here are the commands used to set up rotation:

$ xrandr --output LVDS1 --output VIRTUAL4 --right-of LVDS1 --output VIRTUAL5 --right-of VIRTUAL4 --rotate left
$ xrandr -d :8 --output DP-1 --output DP-2 --right-of DP-1 --rotate left

Everything still works, except for updating pixels 1200-1920 on the vertical.

Xorg.0.log follows. What's a DDX?

Do you still need xrandr --verbose?
Comment 16 Kirill Müller 2013-11-25 15:15:48 UTC
Created attachment 89758 [details]
Xorg.0.log
Comment 17 Chris Wilson 2013-11-25 15:22:17 UTC
(In reply to comment #15)
> Xorg.0.log follows. What's a DDX?

ddx = display dependent X, i.e. the hardware driver portion of X - xf86-video-intel

> Do you still need xrandr --verbose?

Please. I want to see what it reports the available rotation modes as, and what the current is.
Comment 18 Kirill Müller 2013-11-25 16:01:24 UTC
Created attachment 89760 [details]
xrandr -d :0 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b, second try)
Comment 19 Kirill Müller 2013-11-25 16:01:47 UTC
Created attachment 89761 [details]
xrandr -d :8 --verbose (Ubuntu 13.10 system with stock Intel driver after intel-virtual-output -b, second try)
Comment 20 Kirill Müller 2013-11-25 16:02:55 UTC
I usually say `make && sudo make install` and then reboot. Hope that gets the DDX set up.
Comment 21 Chris Wilson 2013-11-25 16:16:12 UTC
Hmm, xrandr is working as I would expect. Can I ask you do a git pull and repeat your testing (but exclude the final xrandr -d :8 fixup) and attach the fresh Xorg.0.log, ivo.txt, xrandr --verbose -d :0 and xrandr --verbose -d :8
Comment 22 Kirill Müller 2013-11-25 16:27:50 UTC
Created attachment 89763 [details]
as requested
Comment 23 Kirill Müller 2013-11-25 16:28:09 UTC
Created attachment 89764 [details]
as requested
Comment 24 Kirill Müller 2013-11-25 16:28:22 UTC
Created attachment 89765 [details]
as requested
Comment 25 Kirill Müller 2013-11-25 16:29:31 UTC
Created attachment 89766 [details]
as requested

in this order:

- Xorg.0.log
- xrandr :0, :8
- ivo.txt

After pulling, make-ing, installing and restarting. No rotation applied to DP-2.

Thanks for looking into it, I'm in a hurry now.
Comment 26 Chris Wilson 2013-11-25 16:58:04 UTC
Ah, it fails to apply the rotated mode. Probably because the fb is too small for the rotated mode. Update for you to test.
Comment 27 Kirill Müller 2013-11-26 08:22:13 UTC
Created attachment 89813 [details]
as usual
Comment 28 Kirill Müller 2013-11-26 08:22:36 UTC
Created attachment 89814 [details]
as usual
Comment 29 Kirill Müller 2013-11-26 08:22:53 UTC
Created attachment 89815 [details]
as usual
Comment 30 Kirill Müller 2013-11-26 08:25:59 UTC
Created attachment 89816 [details]
as usual

Same order as before.

Now the third display is rotated properly, no need to say `xrandr -d :8 --rotate left`. However, on the third display the part below 1200 pixels to the vertical is still black. This even happens if the second display is below the first, and the third is right of the first (so that display areas actually overlap).

The `ivo6.txt` shows how I move the mouse into the black area, and also how I drag a window to the black area (and back). Something on my system (perhaps the `DISPLAY` applet) remembers how I want the screens to be set up, so I didn't have to do anything w.r.t. that for this run.
Comment 31 Kirill Müller 2013-11-26 08:35:03 UTC
Created attachment 89818 [details]
Screenshot of
Comment 32 Kirill Müller 2013-11-26 08:36:20 UTC
...entire desktop. It seems to have proper dimensions, it's just that the "real" display (DP-2) doesn't get updated in this configuration (the lower area of the right display is blank).
Comment 33 Kirill Müller 2013-11-26 08:37:44 UTC
Created attachment 89819 [details]
Screen-shot with proper MIME type
Comment 34 Chris Wilson 2013-11-26 08:54:18 UTC
Getting closer...

commit 63a964d6d0cb0e4ffce70d8e1b672dd65fae6703
Author: Chris Wilson <chris@chris-wilson.co.uk>
Date:   Tue Nov 26 08:52:39 2013 +0000

    intel-virtual-output: Correct clip region of rotated outputs in source framebuffer
Comment 35 Kirill Müller 2013-11-26 10:27:02 UTC
Bingo!

Thanks a lot for your help and for the ultrafast response times. When can I expect this version to appear in the default Ubuntu repos? Or do I have to use Xorg-edgers or Swat or ...?
Comment 36 Chris Wilson 2013-11-26 10:44:31 UTC
In theory, it should pop up in xorg-edgers within 48 hours - but I think it is being a little slow lately. Before it gets updated in Ubuntu proper, I need to make a release - I'm trying to get some new bits together for a new snapshot and a proper release, but since Ubuntu is already lagging behind a couple of snapshots, we may not see an update until they focus on the display server for 14.04 (i.e. it may be a month or two yet).
Comment 37 Kirill Müller 2013-11-26 10:46:41 UTC
I kind of expected that. Would you recommend running everything from stock Ubuntu and only install the Intel driver from edgers in a production system?
Comment 38 Chris Wilson 2013-11-26 10:57:33 UTC
Yes. The driver should function as a drop in replacement on any system (the only caveat is that it has to be compiled for that system to get the right ABI) for the past 7 years or so.
