The libva h264 capture feature in weston generates corrupt results when output is using rgb565 gbm-format (16bpp). Format xrgb8888 (32bpp) works fine. ::Steps:: 1. In weston.ini, set the gbm-format for the output to rgb565, for example: [output] name=HDMI1 gbm-format=rgb565 2. Launch weston 3. Start h264 capture with: <mod>+<shift>+<space> q 4. Do stuff (i.e. launch apps, move windows, etc.) 5. Stop h264 capture with: <mod>+<shift>+<space> q 6. Playback capture.h264 $ gst-play-1.0 capture.h264 or $ gst-launch-1.0 filesrc location=capture.h264 \ ! h264parse ! vaapidecode ! vaapisink 7. Transcode capture.h264 to capture.mp4 $ gst-launch-1.0 filesrc location=capture.h264 \ ! h264parse ! mp4mux ! filesink location=capture.mp4 Kernel: 3.13.6-200.fc20 Systemd: 212 (rawhide) wayland (master) 1.4.92-0-g4a4523f drm (master) libdrm-2.4.52-0-g46d451c mesa (master) heads/master-0-gd55e5a3 libva (master) libva-1.2.1-0-g88ed1eb intel-driver (master) 1.2.2-0-g121e70d cairo (1.12) heads/1.12-0-g59e2a93 libinput (master) heads/master-0-g97af5c3 weston (master) 1.4.92-0-gd7d71e8 gstreamer (1.2) heads/1.2-0-gf8c6552 gst-plugins-base (1.2) heads/1.2-0-gcf5f7cf gst-plugins-good (1.2) heads/1.2-0-g28d65fb gst-plugins-bad (1.2) heads/1.2-0-g4f01875 gst-ffmpeg (1.2) 1.2.4-0-g72f6cb6 gstreamer-vaapi (master) tags/0.5.8-0-gc9af9a8
Created attachment 98344 [details] Screenshot of captured playback
The problem is that we don't appropriately set the format when initializing the VA pipeline, so it just assumes the buffer is in 24 bit depth. However, at the moment libva doesn't even define a RGB565 format. I'm looking into implementing support for this format in libva.
(In reply to comment #2) > The problem is that we don't appropriately set the format when initializing > the VA pipeline, so it just assumes the buffer is in 24 bit depth. However, > at the moment libva doesn't even define a RGB565 format. I'm looking into > implementing support for this format in libva. This doesn't seem like a trivial task, so for the moment I sent a patch to the mailing list so that we don't attempt to record from an output with an unsupported format.
commit 2ef1cd177e73173d8cd25325ce691a09187134cb Author: Ander Conselvan de Oliveira <ander.conselvan.de.oliveira@intel.com> Date: Tue May 6 16:49:06 2014 +0300 compositor-drm: Don't use vaapi recorder with unsupported formats We only support recording with GBM_FORMAT_XRGB888 format, so don't try to record if the output has a differnt format. https://bugs.freedesktop.org/show_bug.cgi?id=78199
