Do you mind reverting that commit chunk-by-chunk to narrow down which bo are suspect? It implies the request tracking is wrong either at the ddx or kernel level, but most likely it is a foriegn bo which the ddx has mistakenly assumed is idle. Along those lines

diff --git a/src/sna/kgem.c b/src/sna/kgem.c
index 8e5ec51..f593abd 100644
--- a/src/sna/kgem.c
+++ b/src/sna/kgem.c
@@ -7003,8 +7003,10 @@ void kgem_bo_sync__cpu(struct kgem *kgem, struct kgem_bo *bo)
        assert(!bo->scanout);
        assert_tiling(kgem, bo);

-       if (bo->rq == NULL && (kgem->has_llc || bo->snoop))
+       if (bo->rq == NULL && (kgem->has_llc || bo->snoop)) {
+               assert(!__kgem_busy(kgem, bo->handle));
                return;
+       }

        kgem_bo_submit(kgem, bo);

@@ -7043,8 +7045,10 @@ void kgem_bo_sync__cpu_full(struct kgem *kgem, struct kgem_bo *bo, bool write)
        assert(!bo->scanout || !write);
        assert_tiling(kgem, bo);

-       if (bo->rq == NULL && (kgem->has_llc || bo->snoop))
+       if (bo->rq == NULL && (kgem->has_llc || bo->snoop)) {
+               assert(!__kgem_busy(kgem, bo->handle));
                return;
+       }

        if (write || bo->needs_flush)
                kgem_bo_submit(kgem, bo);
@@ -7093,8 +7097,10 @@ void kgem_bo_sync__gtt(struct kgem *kgem, struct kgem_bo *bo)
        assert(bo->proxy == NULL);
        assert_tiling(kgem, bo);

-       if (bo->rq == NULL)
+       if (bo->rq == NULL) {
+               assert(!__kgem_busy(kgem, bo->handle));
                return;
+       }

        kgem_bo_submit(kgem, bo);

plus a full-debug log would help.

Also would be nice to check if

diff --git a/src/sna/kgem.c b/src/sna/kgem.c
index 8e5ec51..0b621b6 100644
--- a/src/sna/kgem.c
+++ b/src/sna/kgem.c
@@ -7003,7 +7003,7 @@ void kgem_bo_sync__cpu(struct kgem *kgem, struct kgem_bo *bo)
        assert(!bo->scanout);
        assert_tiling(kgem, bo);

-       if (bo->rq == NULL && (kgem->has_llc || bo->snoop))
+       if (bo->rq == NULL && (kgem->has_llc || bo->snoop) && !bo->flush)
                return;

        kgem_bo_submit(kgem, bo);
@@ -7043,7 +7043,7 @@ void kgem_bo_sync__cpu_full(struct kgem *kgem, struct kgem_bo *bo, bool write)
        assert(!bo->scanout || !write);
        assert_tiling(kgem, bo);

-       if (bo->rq == NULL && (kgem->has_llc || bo->snoop))
+       if (bo->rq == NULL && (kgem->has_llc || bo->snoop) && !bo->flush)
                return;

        if (write || bo->needs_flush)
@@ -7093,7 +7093,7 @@ void kgem_bo_sync__gtt(struct kgem *kgem, struct kgem_bo *bo)
        assert(bo->proxy == NULL);
        assert_tiling(kgem, bo);

-       if (bo->rq == NULL)
+       if (bo->rq == NULL && !bo->flush)
                return;

        kgem_bo_submit(kgem, bo);

affected the rendering.

Tested with the first patch, built with debug=full (and as expected, hit one of the asserts) and produced this log:

http://tnsp.org/~ccr/intel-gfx/sna_skip_sync/Xorg.0.log.old.xz

With the latter patch the problem seems to disappear. Do you want me to test with partial reverts in addition to those? Or something else?

No, the full-debug should be enough to trace back the origin of the busy handle and confirm if it is an external bo (and verify if the mitigation I have in mind will work).

commit 9df8119e1e8216d11a116fdc28c1b499a521ef8b
Author: Chris Wilson <chris@chris-wilson.co.uk>
Date:   Sat Feb 13 08:44:15 2016 +0000

    sna: Reorder busyness checks after finding the proxy's parents

    Due to the way request tracking on proxies work, we need to inspect the
    parent and not the proxy itself.

    Reported-by: Matti Hämäläinen <ccr@tnsp.org>
    References: https://bugs.freedesktop.org/show_bug.cgi?id=94125
    Signed-off-by: Chris Wilson <chris@chris-wilson.co.uk>

Probably needs another pass through with the asserts though.

Pulled and now testing with added asserts. The issue is not presenting (with 1h of testing), nor am I hitting the asserts - so it is working, but that kinda raises the question whether I _should_ hit the asserts at some point? E.g. how to hit the situation the original changeset was meant to address?

(In reply to Matti Hämäläinen from comment #5)
> Pulled and now testing with added asserts. The issue is not presenting (with
> 1h of testing), nor am I hitting the asserts - so it is working, but that
> kinda raises the question whether I _should_ hit the asserts at some point?
> E.g. how to hit the situation the original changeset was meant to address?

The original regressing patch was a micro-optimisation to avoid a syscall and  walking a potentially long list of requests in the kernel (trying to keep that list alive to reduce future work).

Any time we read back from a pixmap, I expect (at least the second time) to hit the short-circuit so given a workload where you saw a failure, I would expect it still be taking the short-circuit, just less often (having avoided the bug).

Thanks for the explanation. I realized that as I was using the assert() conditions from your original patch, they might not trigger, so added some appropriate printf-debugs and those did show that the short-circuit paths are working. ( http://tnsp.org/~ccr/intel-gfx/sna_skip_sync/test_patch.diff )

In conclusion, I guess this works as expected now? :)

Decided to revert the shortcircuit on the write side:

commit aacc3442bb8c280a6ebc1fc1e34451613a72d7c4
Author: Chris Wilson <chris@chris-wilson.co.uk>
Date:   Thu Feb 18 10:15:11 2016 +0000

    sna: Restrict set-domain short-circuit to readonly

    If we write to the bo, we do want the kernel to mark it as dirty (for
    the purposes of swap invalidation and the like), so we can't apply the
    shortcircuit.

    Signed-off-by: Chris Wilson <chris@chris-wilson.co.uk>

that should almost completely nerf the commit (except iirc you will still hit the shortcircuit!).
