Bug 32422 - [RADEON:KMS:TTM] large images displayed in Firefox appear corrupted
Summary: [RADEON:KMS:TTM] large images displayed in Firefox appear corrupted
Status: REOPENED
Alias: None
Product: DRI
Classification: Unclassified
Component: DRM/Radeon (show other bugs)
Version: unspecified
Hardware: x86 (IA32) Linux (All)
: medium normal
Assignee: Default DRI bug account
QA Contact:
URL:
Whiteboard:
Keywords:
Depends on:
Blocks:

Reported: 2010-12-15 11:28 UTC by Da Fox
Modified: 2012-03-15 04:03 UTC (History)
1 user (show)

See Also:
i915 platform:
i915 features:


Attachments
Picture describing a thousand words. (708.95 KB, image/png)
2010-12-15 11:28 UTC, Da Fox
no flags Details
xorg log (42.29 KB, text/plain)
2010-12-15 11:35 UTC, Da Fox
no flags Details
output of /var/log/messages since bootup (190.90 KB, patch)
2010-12-15 11:42 UTC, Da Fox
no flags Details | Splinter Review
Always include CPU domain for BO eviction (597 bytes, patch)
2010-12-21 01:48 UTC, Michel Dänzer
no flags Details | Splinter Review
Image corruption on Firefox (162.67 KB, image/png)
2011-08-12 09:38 UTC, druidic
no flags Details
Some additional debugging output for the failure (1.02 KB, patch)
2011-08-15 02:44 UTC, Michel Dänzer
no flags Details | Splinter Review

Note You need to log in before you can comment on or make changes to this bug.
Description Da Fox 2010-12-15 11:28:26 UTC
Created attachment 41150 [details]
Picture describing a thousand words.

"A picture says more than a thousand words" (aka see attachment)

This is what happens when I try to view the XKCD "Online Communities 2" map (http://xkcd.com/802_large/) or other large images in firefox.
Comment 1 Da Fox 2010-12-15 11:30:51 UTC
(In reply to comment #0)
> Created an attachment (id=41150) [details]
> Picture describing a thousand words.
>
> "A picture says more than a thousand words" (aka see attachment)
>
> This is what happens when I try to view the XKCD "Online Communities 2" map
> (http://xkcd.com/802_large/) or other large images in firefox.

Additional information:
This only happens with 'Option NoAccel="false"' in xorg.conf. Enabling NoAccel (e.g. turning acceleration OFF, using 'softpipe') the image renders as expected.
Comment 2 Alex Deucher 2010-12-15 11:32:20 UTC
What GPU is this?  Can you attach your xorg log and dmesg?
Comment 3 Da Fox 2010-12-15 11:35:43 UTC
Created attachment 41151 [details]
xorg log
Comment 4 Da Fox 2010-12-15 11:42:19 UTC
Created attachment 41152 [details] [review]
output of /var/log/messages since bootup
Comment 5 Da Fox 2010-12-15 11:48:18 UTC
Hardware is an IBM Thinkpad T42, which has a ATI Radeon 9600 Mobility M10 / rv350 graphics card.
Comment 6 Alex Deucher 2010-12-15 12:11:49 UTC

*** This bug has been marked as a duplicate of bug 31708 ***
Comment 7 Manuel Lauss 2010-12-15 12:22:40 UTC
(In reply to comment #6)
>
> *** This bug has been marked as a duplicate of bug 31708 ***

I don't think this bug is related to 31708:  Even with the patch for bug 31708
applied, I see the same corruption in firefox (and only firefox; chrome, imagemagick, the KDE image viewer for example all display these large images correctly).
Comment 8 Michel Dänzer 2010-12-16 08:40:47 UTC
(In reply to comment #7)
> Even with the patch for bug 31708 applied, I see the same corruption in firefox [...]

That's with the latest version (v3) of the patch? (Jerome even submitted v4 later, but I don't think the difference from v3 should be relevant for this problem; wouldn't hurt to try of course)
Comment 9 Da Fox 2010-12-20 10:35:54 UTC
(In reply to comment #8)
> (In reply to comment #7)
> > Even with the patch for bug 31708 applied, I see the same corruption in firefox [...]
>
> That's with the latest version (v3) of the patch? (Jerome even submitted v4
> later, but I don't think the difference from v3 should be relevant for this
> problem; wouldn't hurt to try of course)

I have tried with the version present in 2.6.37-rc6, which according to the changelog (http://www.kernel.org/pub/linux/kernel/v2.6/testing/ChangeLog-2.6.37-rc6) is v3.

ps.
I only noticed that there were new posts on this bug after submitting my comment on the other bug.
Comment 10 Michel Dänzer 2010-12-21 00:14:02 UTC
Really looks like a separate bug.
Comment 11 Michel Dänzer 2010-12-21 01:48:11 UTC
Created attachment 41339 [details] [review]
Always include CPU domain for BO eviction

Does this patch help?

Though even if it does, I don't understand why it fails to evict to GTT with Jerome's v3 fix, might be interesting to add some debugging output to find out why ttm_bo_mem_space() fails.
Comment 12 Da Fox 2010-12-21 14:22:11 UTC
(In reply to comment #11)
> Created an attachment (id=41339) [details]
> Always include CPU domain for BO eviction
>
> Does this patch help?
>
> Though even if it does, I don't understand why it fails to evict to GTT with
> Jerome's v3 fix, might be interesting to add some debugging output to find out
> why ttm_bo_mem_space() fails.

Sorry, it still fails to render properly. I did notice that at least for the xkcd image it sometimes displays properly, even with only the v3 patch. However I haven't yet been able to determine when this happens. I just happened to notice this because I left the xkcd image open in a tab, and when I later came back to that tab I could see the whole image and pan around without issue. I also don't know yet if this also happens on 2.6.36, I would need to 'test'(try) that.
Comment 13 druidic 2011-08-12 09:34:01 UTC
I've had this same issue for ages on X1400. I has been seemingly random, but always with large images. With this one I can finally reproduce it reliably! Just pan around the xkcd-image for a while, keep switching between tabs and it will happen eventually.
Comment 14 druidic 2011-08-12 09:38:47 UTC
Created attachment 50166 [details]
Image corruption on Firefox

linux-3.0.1
xf86-video-ati-6.14.2
xorg-server-1.10.3.901
firefox-5.0
Comment 15 Michel Dänzer 2011-08-15 02:44:43 UTC
Created attachment 50224 [details] [review]
Some additional debugging output for the failure

Please attach dmesg from reproducing the problem with this kernel patch applied.
Comment 16 druidic 2011-08-15 08:39:26 UTC
Ah. Sorry. I examined the original reporter's logs and compared them to mine. I have no errors in dmesg related to TTM (or anything else for that matter) whatsoever. Or do I need to enable some particular debugging?

Might be that my problem is different - however the symptoms are identical.
Comment 17 Da Fox 2012-03-15 04:02:49 UTC
asasassadadasdasdasdasdasdadasdad
Comment 18 Da Fox 2012-03-15 04:03:48 UTC
(In reply to comment #17)
> asasassadadasdasdasdasdasdadasdad

I'm terribly sorry, please ignore that.
