Bug 865 - [XKB] need to kick hotkeys on release, not press
[XKB] need to kick hotkeys on release, not press
Status: ASSIGNED
Product: xorg
Classification: Unclassified
Component: Server/Input/Core
git
Other Linux (All)
: high major
Assigned To: Xorg Project Team
Xorg Project Team
2011BRB_Reviewed
:
: 731 10662 12085 16041 18333 (view as bug list)
Depends on:
Blocks: xserver-1.13
  Show dependency treegraph

Reported: 2004-07-14 02:58 UTC by Vitaly Shishakov
Modified: 2014-10-04 16:00 UTC (History)
54 users (show)

See Also:


Attachments
This patch is to resolve the issue; it is for "trunk" Xorg sources. (3.14 KB, patch)
2010-02-07 14:17 UTC, Ilya Murav'jov
no flags Details | Splinter Review
The same patch, but based on 1.12.0.902 (3.38 KB, patch)
2012-04-10 11:01 UTC, kyak
no flags Details | Splinter Review
xorg-server-1.12.2-xkb-switch-on-release.patch (3.74 KB, patch)
2012-06-23 12:55 UTC, Alon Bar-Lev
no flags Details | Splinter Review
LockMods can lock another group (2.13 KB, patch)
2012-10-28 16:37 UTC, Andreas Wettstein
no flags Details | Splinter Review
LockMods can lock another group (2.19 KB, patch)
2012-10-29 08:43 UTC, Andreas Wettstein
no flags Details | Splinter Review

Note You need to log in before you can comment on or make changes to this bug.
Description Vitaly Shishakov 2004-07-14 02:58:37 UTC
I used to use Ctrl-Shift combination to switch keyboard layouts (ru <--> us)
but in this case i cant use any of the Ctrl-Shift-* hotkeys in any software i try.

I noticed, that the keyboard layout becomes swithced as soon an both keys are DOWN --
pressing any other key is not treated as Ctrl-Shift-<key> combination.

For example -- in Windows i also use Ctrl-Shift to switch layouts, but there, the layout
becomes switched only when both SHIFT and CTRL keys are UP, and no other key was
pressed while they were down -- in that case the hole combination is treates as
Ctrl-Shift-<key> combination, and the layout is not changed.

see also:  http://bugs.kde.org/show_bug.cgi?id=59303



I use the following lines in XF86Config:

Section "InputDevice"
  Driver       "Keyboard"
  Identifier   "Keyboard[0]"
  Option       "Protocol" "Standard"
  Option       "XkbLayout" "us,ru"
  Option       "XkbModel" "pc104"
  Option       "XkbOptions" "grp:ctrl_shift_toggle"
  Option       "XkbRules" "xfree86"
  Option       "XkbVariant" ",winkeys"
EndSection
Comment 1 Kristian Høgsberg 2004-07-25 13:56:15 UTC
*** Bug 731 has been marked as a duplicate of this bug. ***
Comment 2 Erik Andren 2006-05-19 04:47:14 UTC
Are you able to reproduce this issue with a current version of xorg?
Comment 3 Daniel Stone 2006-06-01 16:56:02 UTC
yep, it's still a current issue.  reasonably non-trivial fix, though.  we could
probably hijack PKE for this.
Comment 4 Vitaly Shishakov 2006-08-02 16:33:27 UTC
(In reply to comment #2)
> Are you able to reproduce this issue with a current version of xorg?

playing with current xorg 7.1 on SuSE 10.1, taken from SuSE repositories.
it still behaves the same.
Comment 5 Daniel Stone 2007-02-27 01:23:43 UTC
Sorry about the phenomenal bug spam, guys.  Adding xorg-team@ to the QA contact so bugs don't get lost in future.
Comment 6 Daniel Stone 2007-04-17 08:25:24 UTC
*** Bug 10662 has been marked as a duplicate of this bug. ***
Comment 7 nonZero 2007-05-02 16:17:16 UTC
    Reproduced on Ubuntu 7.04.

    I would be happy to beta test patches were group change occurs at release, and
    only if no other key combination was pressed, i.e:
    in my configuration alt+shift chages group.
    alt+shift+tab should go back a window and NOT change a group.
    currently it changes a group and do goes a window forward!

    Thanx,
    nonZero

Comment 8 Alon Bar-Lev 2007-08-17 12:43:29 UTC
I have the same issue with Hebrew layout...
<Alt><Shift><Tab> changes language on <Alt><Shift> key-down and not go back window as expected.

Well... long time until I thought I should file a bug... :)
Comment 9 Daniel Stone 2007-08-21 07:13:56 UTC
*** Bug 12085 has been marked as a duplicate of this bug. ***
Comment 10 Tassilo Horn 2007-12-03 09:40:12 UTC
I use

  Option      "XkbOptions"      "ctrl:nocaps"

and have related problems.  When I want to type a keybinding like C-M-a (C = Control, M = Meta (Alt)) and type it by first pressing Control, then Alt and then "a" it's translated to C-a.  The Alt is blocked when I hit Control first.  xev shows this order of events:

  KP-C, KP-a, KR-a, KP-M, KR-M, KR-C

where KP stands for KeyPress and KR for KeyRelease.  If I comment out the Option line from above in my xorg.conf, all works fine.

If I type C-M-a by first pressing Alt, then Control and then "a" it works, too.
Comment 11 Alex Morgun 2008-01-20 12:45:51 UTC
This bug will touch all EX-WINDOWS users that use more then one language in their system. It was the major drawback when i found it.
Comment 12 Alon Bar-Lev 2008-04-12 05:20:35 UTC
Hello Xorg developers,

Can you please look at this issue?
It is very important to fix this for regular users to be able to use this environment.
It basically effects all multi-language users, and regular users are not able to accept the keydown/keyup explanations...

Thanks!
Comment 13 Peter Hutterer 2008-05-20 16:36:19 UTC
*** Bug 16041 has been marked as a duplicate of this bug. ***
Comment 14 Maciej Pilichowski 2008-05-21 01:43:07 UTC
Hmm, I am not that sure my report is a duplicate -- but if yes, differences:

* I don't do any layout switching, I have only single layout

* issue I described has nothing to do with pressing or releasing

* the problem is that you can assign shift key to keyboard shortcuts like shift+F1 but you cannot assign alt key (shift level3) to such combinations -- in other words, such key can generate only characters (specified in layout) but beside that it is a dead key
Comment 15 Daniel Stone 2008-05-21 03:51:20 UTC
On Wed, May 21, 2008 at 01:43:08AM -0700, bugzilla-daemon@freedesktop.org wrote:
> Hmm, I am not that sure my report is a duplicate -- but if yes, differences:
>
> * I don't do any layout switching, I have only single layout
>
> * issue I described has nothing to do with pressing or releasing
>
> * the problem is that you can assign shift key to keyboard shortcuts like
> shift+F1 but you cannot assign alt key (shift level3) to such combinations --
> in other words, such key can generate only characters (specified in layout) but
> beside that it is a dead key

Yes, Fn keys acting differently is another bug, but one that's fixable
by changing the keyboard layout definition of Ctrl+Alt.
Comment 16 Maciej Pilichowski 2008-05-21 04:04:58 UTC
Daniel, thank you for the answer. Further clarification (just in case):

a) F1 was just an example -- alt+left, alt+enter, alt+<anything not defined as character> is not working.

b) I don't use ctrl+alt, I use only alt (for getting special characters, in fact since alt is a key I cannot use anymore (*) I cannot use alt+ctrl anywhere by definition)

c) alt also is an example, in general it is shift level 3 key, it could be meta key as well

(*) sorry for using term "dead key", it has special meaning in X (other than I meant)

In short my wish is:
alt+c --> ć (character)
alt+f --> alt+f (key combo; so I could use in KDE as a keyboard shortcut)
Comment 17 Alon Bar-Lev 2008-10-10 11:24:58 UTC
Hello,
Is there any news for this one?
It is very annoying issue.
Thanks!
Comment 18 Daniel Stone 2008-10-31 18:12:06 UTC
*** Bug 18333 has been marked as a duplicate of this bug. ***
Comment 19 Mike 2008-11-11 13:07:56 UTC
this is really annoying bug to me. I can't use Eclipse IDE for programming, because all hotkeys use either ctrl+shift+something or ant+shift. In other words instead of refactoring I get russian letters which replace my code.

I cant switch to different (like caps lock) swith mode, since I use both linux and windows too often, and it is very inconvenient to use different methods.

Is there a way I can help coding it? any narration from where I should start in sources?
Comment 20 Peter Hutterer 2008-11-12 20:35:47 UTC
xserver/xkb/xkbActions.c is where the action handling happens. There is little
documentation aside from the XKB protocol spec, so you need to dig through the
code to figure out what actually happens.

The entry point for xkb is ProcessKeyboardEvent, it's the first function
called when a keyboard event occurs. Anthing before doesn't matter to you.
Comment 21 Alexander Kojevnikov 2009-02-23 16:33:22 UTC
Does someone work on this? It's a very annoying bug, a lot of Emacs shortcuts don't work because of it.
Comment 22 Peter Hutterer 2009-02-25 01:03:13 UTC
> --- Comment #21 from Alexander Kojevnikov <alexander@kojevnikov.com>  2009-02-23 16:33:22 PST ---
> Does someone work on this?

Not that I know of. Any help would be much appreciated.
Comment 23 E 2009-03-06 03:16:52 UTC
Can we solve this problem?
I've made some digg about key codes, may be this can be helpful?
https://bugs.launchpad.net/ubuntu/+source/xorg-server/+bug/292260/comments/6
Does anybody know: Russian distros like AltLinux or AspLinux have this poblem? Perhaps we can take some code from there?
Comment 24 Adam Purkrt 2009-03-08 09:40:36 UTC
--- Introduction

I'd like to discuss this problem in more detail and hopefully add some ideas. For the sake of concreteness, I'm mostly discussing the "Alt+Shift bound to layout switch and preventing other Alt+Shift keyboard shortcuts" case.

After some research, I have the feeling that the problem is in the XKB protocol itself and not in its implementation, which just correctly adheres to a deficient specification. It is the XKB protocol that needs to be extended to properly cover the requested behaviour. Seems to me that currently one can bind actions only to keypresses (please correct me if I'm wrong).

Admittedly, the fix is non-trivial. But it would be worth it; the current behaviour is clumsy and limiting and (as has been said before) e.g. disallows the use of "Alt+Shift+Tab" shortcut, commonly used to switch among open windows, when "Alt+Shift" is used to switch between layouts (that's actually how I found this bug - searching why Alt+Shift+Tab doesn't work).



--- Definition of "multi-key-press-release sequence"

Definition: A "multi-key-press-release sequence" (MKPR seq. for short) is a sequence of key presses and key releases occuring on a keyboard. It begins and ends with all keys on keyboard up. During the sequence, there must always be at least one key down.



--- The desired behaviour - the simple case with two layouts

Initial state: no key is pressed on the keyboard, two layouts are set in the X server (us,cz), layout "us" selected (locked)

The user's intention: to select (lock) the "cz" layout

Action taken - a four step MKPR sequence:
1) press (and hold) Alt 2) press Shift 3) release Shift 4) release Alt

The expected behaviour/response: The release of all keys (i.e. step 4) would trigger the selection (and locking) of "cz" layout.

Current behaviour/response: The layout gets changed after step 2). Moreover, XKB then somehow forgets that Shift is still held down and acts as if only Alt was held down. This precludes even the reachability of any shortcut containing "Alt+Shift" combination.

Note on expected behaviour/response: If any key other than Alt or Shift is pressed during the time when Alt was held down, no layout change should occur. In other words, pressing any other key than "Shift" or "Alt" would completely disqualify the MKPR sequence being formed from being a candidate for layout switching.



--- Slight extension

Consider this MKPR seq.:
1) press and hold Alt 2) press Shift 3) release Alt 4) release Shift

That should switch the layout too, as well as this other two possibilities:

1) press and hold Shift 2) press Alt 3) release Alt 4) release Shift

1) press and hold Shift 2) press Alt 3) release Shift 4) release Alt




Unsure: What about the following MKPR seq?

1) press and hold Alt 2) press Shift 3) release Alt 4) press Alt 5) release Shift 6) release Alt

Should this do something special? (probably not, maybe it should not do anything at all)



--- What if there are more than two layouts (e.g. 4 layouts?)

It would be IMHO practical, if the switching among layouts with Alt+Shift could work similarly as Alt+Tab switching between windows in XFCE/GNOME/KDE etc., i.e. there would be some internal recency list, enabling to quickly switch between two most recently used layouts. I.e. press and hold Alt and then press/release Shift multiple times to walk through the possible layouts list, ordered by the time they were last used (more recent first). Release of Alt would then mean "switch to the selected layout". Pressing Esc (or any other key) during the hold of Alt would mean "cancel the switching, leave the current layout".

How would the user be notified about the currently selected "candidate" for switching to during the selection? One possibility is e.g. showing the "layout candidate" in notification area (interaction with desktop environment required).



--- Conclusion

To sum things up, it would be great if the XKB could be extended to cover the notion of "multi-key-press-release" sequence and its use as a trigger for (e.g.) changing keyboard layout.

The "recency-aware" layout switching among more than two layouts seems to me as a good idea also.






--- REFERENCES, some starting points for XKB hacking

http://www.xfree86.org/current/XKBproto.pdf - The XKB Extension: Protocol Specification
http://www.xfree86.org/current/XKB-Config.html - How to configure XKB

/usr/share/X11/xkb/symbols/group - this is the file where e.g. "Alt+Shift" layout switching is defined, namely this part

** beginning of excerpt

partial modifier_keys
xkb_symbols "alt_shift_toggle" {
    virtual_modifiers Alt;
    key <LALT> {
	symbols[Group1]= [ NoSymbol,	ISO_Prev_Group ],
	virtualMods= Alt
    };
    key <RALT> {
	symbols[Group1]= [ NoSymbol,	ISO_Next_Group ],
	virtualMods= Alt
    };
    key <LFSH> {
	type[Group1]="PC_ALT_LEVEL2",
	symbols[Group1]= [ Shift_L,	ISO_Prev_Group ]
    };
    key <RTSH> {
	type[Group1]="PC_ALT_LEVEL2",
	symbols[Group1]= [ Shift_R,	ISO_Next_Group ]
    };
};

** end of excerpt


Some useful commands:

"setxkbmap -option" clears all options
"setxkbmap -v 10 -layout us,cz -option grp:alt_shift_toggle" - setup two layouts, with alt+shift switching between them
"setxkbmap -print -v 10" - print current XKB settings

Try to change e.g. "Shift_R" to "A" in the above mentioned part of /usr/share/X11/xkb/symbols/group, save and then run "setxkbmap us,cz -option grp:alt_shift_toggle" - right shift then should produce the letter "A".
Comment 25 Adam Purkrt 2009-03-08 09:51:33 UTC
another good article about XKB

http://pascal.tsu.ru/en/xkb/setup.html
Comment 26 nonZero 2009-03-08 12:36:10 UTC
(In reply to comment #24)
> Action taken - a four step MKPR sequence:
> 1) press (and hold) Alt 2) press Shift 3) release Shift 4) release Alt
.
.
.
> It would be IMHO practical, if the switching among layouts with Alt+Shift could
> work similarly as Alt+Tab switching between windows in XFCE/GNOME/KDE etc.,
> i.e. there would be some internal recency list, enabling to quickly switch
> between two most recently used layouts. I.e. press and hold Alt and then

To make this happen, the event should be triggered following step 3.
So, basically what needed to be done is whenever a key is pressed, key combination should be matched against the current pressed keys, and if a combination is met exactly, we should only set a flag for this combination - and not actually fire the event.
Whenever a key is released, this flag is checked - if the flag was set, the event shoud be fired and the flag should be cleared.
Whenever a key is pressed, the flag should also be cleared, so:
Example A:
Step    Action                        Flag
----    ----------------------------- ----
                                      0
1       Alt pressed                   0
2       Shift Pressed - match!        1
3       Shift released - EVENT FIRED  0
4       Alt released                  0

Example B:
Step    Action                        Flag
----    ----------------------------- ----
                                      0
1       Alt pressed                   0
2       Shift Pressed - match!        1
3       Tab Pressed                   0
4       Tab released                  0
5       Shift released                0
6       Alt released                  0

Example C:
Step    Action                        Flag
----    ----------------------------- ----
                                      0
1       Alt pressed                   0
2       Shift Pressed - match!        1
3       Shift released - EVENT FIRED  0
4       Shift Pressed - match!        1
5       Shift released - EVENT FIRED  0
6       Alt released                  0

Example D:  (very strange case, unexpected, just for "fun")
Step    Action                        Flag
----    ----------------------------- ----
                                      0
1       Alt pressed                   0
2       Shift Pressed - match!        1
3       Tab Pressed                   0
4       Tab released                  0
5       Shift released                0
4       Shift Pressed - match!        1
5       Shift released - EVENT FIRED  0
6       Alt released                  0

I think this is good enough for 99% of the cases.
I did not dive into the protocol, but I have a feeling that adding such a flag is not a big deal, and does not require a rewrite, but please, correct me if I am wrong.

Udi
Comment 27 Adam Purkrt 2009-03-08 16:11:10 UTC
> To make this happen, the event should be triggered following step 3.
>.
>.
> So, basically what needed to be done is whenever a key is pressed, key
> combination should be matched against the current pressed keys, and if a
> combination is met exactly, we should only set a flag for this combination -
> and not actually fire the event.
> Whenever a key is released, this flag is checked - if the flag was set, the
> event shoud be fired and the flag should be cleared.
>.
>.
> I think this is good enough for 99% of the cases.


Good idea with the flag, and you are probably right that your solution would solve 99% of the cases (since lot of people affected by this probably use just two layouts - US and their national one - at least that is my situation).

Anyway I would be definitely for incorporating the "recency-awareness" into the switching of keyboard layouts. It would be very handy in the case when there is need to switch among more than two layouts.


I know I'm straying quite a bit from the original problem now, since this is definitely a request for extension, but I think it's still in close relation, so let me explain the idea in more detail.


--- First introduce some shorthands

<key> down = press <key> and hold it down
<key> up = release <key>
<key> hit = press <key> and immediately release it


--- What do I mean by "recency-aware" switching and why is it a good idea

Basically it's the type of switching that is used for switching among windows in XFCE/GNOME/KDE, so let's first describe how that works. For example, let's open four applications in say XFCE - first app1, then app2, then app3 and finally app4. By that, subsequently app1 app2 app3 and app4 gets focused (i presume that when the app is opened, it gathers focus). So now app4 is focused. Suppose we want to switch to app2. What one can do is:

1) Alt down
2) Tab down - now a list of applications appears, showing the applications in this order: app4, app3(selected), app2, app1 - it's the order in which they had been lastly focused
3) Tab up
4) Tab down - now app2 gets selected in the applist
5) Tab up
6) Alt up - this release triggers the actual switch, so applist disappears and app2 gets focused; also, the applist gets reordered (internally) - the apps in it are now in this sequence: app2 (currently=most recently focused), app4, app3, app1 (focused longest time ago)

Now suppose we want to switch back from app2 to app4 (typical scenario: app2 is an editor in which one edits a webpage and app4 is a web browser used for testing that page). With recency-aware applist, this can be done easily, thanks to the clever rearrangement of apps in it:

1) Alt down
2) Tab down - list of application appears: app2, app4(selected), app3, app1
3) Tab up
4) Alt up - app4 gets focused

If the list didn't get rearranged (and was still app4,app3,app2,app1) one would need to hit tab twice to get back to app4 (assuming wrap arround). But with recency awareness, it's just "down Alt + hit Tab + up Alt" et voila.

Compare this to e.g. tab switching in Firefox which, by default, is just rudimentary; no recency awareness there. Ctrl+Tab is just "switch one tab to the right", Ctrl+Shift+Tab "switch one tab to the left". Switching back and forth between a pair of tabs, using only keyboard, is not easily accomplished, especially if the tabs aren't next to each other. And even if they are next to each other, each time you switch you have to think about "am I now in the left or in the right tab? should I switch to the right or to the left?" With recency-awareness, it would be just "down Ctrl, hit Tab, up Ctrl" to switch back and forth. I don't want to critize Firefox here. I just want to illustrate how handy the recency awareness in switching can be.


--- Back to recency-aware layout switching - explanation by example

It's basically a direct analogy of recency-aware window switching, with one subtlety - the (optional) dialog appears after the first release of Shift, not the first press.

Let's have four keyboard layouts set in the X server - 'us','cz','de','fr' (ordered from most recently used/locked to the longest-ago locked); i.e. the 'us' layout is the one currently locked, and 'fr' has not been used for the longest time. Now let's say we want to switch to the 'fr' layout. It would work in this way:

1) Alt down
2) Shift down
3) Shift up - now the actual layout switch would begin; in cooperation with desktop environment, some dialog window should (optionally) also appear, displaying the (in our case four) available layouts, with the most recently used layout ('us') on the first place, and the second layout ('cz') selected.
schematically: [ us, *cz, de, fr ] - selection indicated by asterisk here

It is important that the dialog for switching should appear only by now, after the first release of Shift. It could be confusing if the dialog appeared after step 2) since Alt down followed by Shift down can be just beginning of some Alt+Shift+something shorcut (e.g. Alt+Shift+Tab).

4) Shift down - now the 'de' would get selected: [ us, cz, *de, fr ]

The cycling in the list is now triggered by the press, since we now presume that the user wants to switch layouts, it's ok now to have feedback on press.

5) Shift up - nothing happens, 'de' stays selected
6) Shift down - 'fr' gets selected: [ us, cz, de, *fr ]
7) Shift up - nothing happens, 'fr' stays selected

Note: up until now, no actual change of the layout has occured! It's just the selection of the layout we intend to lock that takes place so far. Shift is used to walk (or, rather, cycle) through the list of available layouts as Tab is used to cycle through the list of available windows. The selection of the new layout can be cancelled by pressing e.g. "esc" (similarly as the switching of window can be cancelled by "esc").

8) Alt up - only this release triggers the actual locking of the new, in our case 'fr' layout. The list of layouts disappears, internally it gets rearranged to this state: 'fr', 'us', 'cz', 'de'.



Subsequently with "down Alt + hit Shift + up Alt" one could switch back to 'us' layout etc.



So this is my proposal for keyboard layout switch. It requires changes in the XKB and also in the desktop environments (to display the layout selection window), but the result would be well worth the effort IMO.


Regards,
Adam
Comment 28 Vasa Maximov 2009-04-04 02:25:09 UTC
(In reply to comment #27)
> So this is my proposal for keyboard layout switch. It requires changes in the
> XKB and also in the desktop environments (to display the layout selection
> window), but the result would be well worth the effort IMO.

+1 to Adam's idea. This is how it should work.
Comment 29 Oleg 2009-04-20 21:47:02 UTC
Five years the problem remains not solved.

Developers have no problems with switching of keyboard layouts and hotkeys?

(Sorry for my english)
Comment 30 E 2009-04-21 06:22:34 UTC
(In reply to comment #29)
> Five years the problem remains not solved.
>
> Developers have no problems with switching of keyboard layouts and hotkeys?
>
> (Sorry for my english)
>

Looks like Russian and Slavic users are mainly affected. :(
What about Adam's idea? It looks very good.

Can anybody realize it?  Unfortunately I'm not an Xorg developer :(
Is it possible to make it as a patch? or specific branch?
Comment 31 Oleg 2009-05-12 11:44:09 UTC
www.xneur.ru - switch layouts on key release!
No problem for hotkeys!

xneur - daemon
gxneur - gui for gnome
kxneur - gui on QT for KDE
Comment 32 Ihar Mahaniok 2009-05-12 12:27:59 UTC
Oleg, this blatant self-promotion doesn't make sense here, since the app can't solve the issue. I wasted my time installing it, and there is simply no way to set "Ctrl-Shift" as a combination to switch layouts in it.
Comment 33 Oleg 2009-05-12 12:37:22 UTC
(In reply to comment #32)
> Oleg, this blatant self-promotion doesn't make sense here, since the app can't
> solve the issue. I wasted my time installing it, and there is simply no way to
> set "Ctrl-Shift" as a combination to switch layouts in it.
>

It's not my programm! And no self-promotion!

1. Delete all layoute switch settings on gnome
2. Set at xneur ctrl+shift for Rotate Layout

Result:
ctrl+shift = layout swither
ctrl+shift+... = you hotkey.

It works for me, must can work for you. try.


(sorry for my english)
Comment 34 Ihar Mahaniok 2009-05-12 12:46:05 UTC
hi Oleg,

sorry for my wrong comment, if that's not your program. But
1) there is no "RotateLayout" option there. at least in 0.9.4
2) even if there was, people can't set ctrl-shift regardless of side as binding; you need to choose, left ctrl-shift or right ctrl-shift.

so, unfortunately, it doesn't seem to be a nice solution.
Comment 35 Oleg 2009-05-12 12:57:32 UTC
(In reply to comment #34)
> hi Oleg,
>
> sorry for my wrong comment, if that's not your program. But
> 1) there is no "RotateLayout" option there. at least in 0.9.4

Oh, sorry. "RotateLayouts"  The option has appeared in version 0.9.5 (It is accessible in svn, but non-stable)



> 2) even if there was, people can't set ctrl-shift regardless of side as
> binding; you need to choose, left ctrl-shift or right ctrl-shift.
>
The author now works over it


> so, unfortunately, it doesn't seem to be a nice solution.

Other variants simply are not present.
The problem is not solved five years.

I just try to help.
Comment 36 Oded Arbel 2010-01-25 01:34:48 UTC
Oleg: I tried xneur and it obviously solves some problem for someone, but not this problem for me. For once it doesn't play nice with X.org (if I understand correctly it takes over keyboard input completely and handles it on its own), for second it only supports a small subset of languages supported in X.org and for third its way too complicated.

Adam Purkrt discussion about the changes required, and nonZero's idea for implementation look like a very good thing to implement. I understand from Adam Purkrt's comments that this suggestion conflicts with the specification of the XKB protocol - Is that correct? and if so - can it be implemented regardless in X.org or does the X.org development process calls for the specification to first be changed?

Also regarding the recency list idea described in Adam Purkrt's last comment - I think that the idea in itself is good but the implementation, especially the part where the system should switch from responding to RELEASE event to use PRESS events instead, is way complicated and we should start by getting the "switch on release" working first so that layout switching can actually be done without interfering with shortcuts, and do optimization later.

I'm not an X.org developer, but I'm a programmer by trade and if this can be fixed in X.org (see my previous questions), I would really like to try to put in a fix according to Adam's and nonZero's suggestions. I just wouldn't like to invest a lot of work in this only to find its all for naught, so I'd appreciate some feedback from the developers first (Daniel?) if this is even feasible to do in the X.org code base (i.e. without getting into a large protocol specification process).
Comment 37 Vasily Khoruzhick 2010-01-25 02:30:09 UTC
(In reply to comment #36)
> Also regarding the recency list idea described in Adam Purkrt's last comment -
> I think that the idea in itself is good but the implementation, especially the
> part where the system should switch from responding to RELEASE event to use
> PRESS events instead, is way complicated and we should start by getting the
> "switch on release" working first so that layout switching can actually be done
> without interfering with shortcuts, and do optimization later.

It's not so easy to handle release event instead of press, Xorg handles ctrl+shift combination as _one_ key, so AFAIR release means _both_ ctrl and shift released.

> I'm not an X.org developer, but I'm a programmer by trade and if this can be
> fixed in X.org (see my previous questions), I would really like to try to put
> in a fix according to Adam's and nonZero's suggestions. I just wouldn't like to
> invest a lot of work in this only to find its all for naught, so I'd appreciate
> some feedback from the developers first (Daniel?) if this is even feasible to
> do in the X.org code base (i.e. without getting into a large protocol
> specification process).

Daniel is now working on XKB2, so fixing/changing XKB1 has no sense :)
Comment 38 Oded Arbel 2010-01-25 04:22:19 UTC
(In reply to comment #37)
> It's not so easy to handle release event instead of press, Xorg handles
> ctrl+shift combination as _one_ key, so AFAIR release means _both_ ctrl and
> shift released.

I'm not sure why you say that - xev detects CTRL and SHIFT independently.


> Daniel is now working on XKB2, so fixing/changing XKB1 has no sense :)

Will XKB2 address this issue? I've looked for information on XKB2 on the web and there is very little information to be found except that it aims to handle input-methods better and that it won't bee in the next X.org release (after missing the last three as well).

So this is another area where I would appreciate some feed back from developers - if XKB2 realistic for X.org 1.9, then maybe I should help out with that. Otherwise, I don't see what's wrong with fixing XKB1 for 1.9 even if only for this release.
Comment 39 Vasily Khoruzhick 2010-01-25 05:12:52 UTC
(In reply to comment #38)
> I'm not sure why you say that - xev detects CTRL and SHIFT independently.

You did not notice ISO_Next_Group which appears when CTRL and SHIFT pressed at same time.

> Will XKB2 address this issue? I've looked for information on XKB2 on the web
> and there is very little information to be found except that it aims to handle
> input-methods better and that it won't bee in the next X.org release (after
> missing the last three as well).

I don't know :) I didn't find any info about XKB2 too.
Comment 40 Oded Arbel 2010-01-25 05:48:59 UTC
(In reply to comment #39)
> (In reply to comment #38)
> > I'm not sure why you say that - xev detects CTRL and SHIFT independently.
>
> You did not notice ISO_Next_Group which appears when CTRL and SHIFT pressed at
> same time.

Oh, I though you meant CTRL+SHIFT as in the actual keys, not as "the keyboard layout switching combination you currently have set" (which is not CTRL+SHIFT in my system).

Indeed it does - but that is internal to the XKB implementation and the reason for this bug and not something inherent to X.org itself (other then the XKB part). And we want to change that.

Also, notice that the current implementation looks like this:
1. hold down <1st key of combination>: you get "KeyPress <1st key>"
2. hold down <2nd key of combination>: you get "KeyPress ISO_Prev_Group" (or ISO_Next_Group. I get "prev", not sure why - maybe its a GNOME thing).
3. release <2nd key of combination>: you get "KeyRelease ISO_Prev_Group".
4. release <1st key of combination>: you get "KeyRelease <1st key>"

On the other hand, notice how the current implementation handles a different release order (take it from after step 2 above):
3. release <1st key of combination>: you get "KeyRelease <1st key>"
4. release <2nd key of combination>: you get "KeyRelease <2nd key>"

So in effect, with the alternate sequence, you get a <1st key> press and release, but only ISO_sth_Group press and only <2nd key> release. As I was trained to change layouts quickly, I cannot always guarantee that I release the keys in the order they were pressed, and releasing them out of order causes some problems like the notorious "sticky keys" issue.
Comment 41 Nick Andrik 2010-01-25 05:51:11 UTC
First of all I have the same problem (while switching to greek layout).

A simple solution I see on this is to act only on release events and only if the previous event was a press. Like this all the situations in comment: #26 are handled correctly.

The things needed from the implementation point of view are:
- A variable (e.g. previous_event_type) which tells us if the previous event was a "press" one which should get updated on every event
- A way to find what combination of keys has just been released (I guess this is already there, for the "has just been pressed" case).

I tried to take a look in the xkbActions.c file (xorg-server-1.7.3.902) but I could not find the ProcessKeyboardEvent function mentioned on comment: #20.
Any info on this? I could try to create a patch for this but I need the correct pointers on where to look.
Comment 42 Vasily Khoruzhick 2010-01-25 06:08:42 UTC
(In reply to comment #41)
> I tried to take a look in the xkbActions.c file (xorg-server-1.7.3.902) but I
> could not find the ProcessKeyboardEvent function mentioned on comment: #20.
> Any info on this? I could try to create a patch for this but I need the correct
> pointers on where to look.

It seems it's in xkbPrKeyEv.c now
Comment 43 James Cloos 2010-01-25 10:00:48 UTC
> you get "KeyPress ISO_Prev_Group" (or ISO_Next_Group. I get "prev", not sure why

The xkb rules send ISO_Next_Group if you press the relevent keys in one
order and ISO_Prev_Group if you press them in the other order.

Eg, given group(ctrls_toggle), LCtrl+RCtrl does next and RCtrl+LCtrl does prev.
Comment 44 Oded Arbel 2010-01-26 00:30:09 UTC
(In reply to comment #43)
> > you get "KeyPress ISO_Prev_Group" (or ISO_Next_Group. I get "prev", not sure why
>
> The xkb rules send ISO_Next_Group if you press the relevent keys in one
> order and ISO_Prev_Group if you press them in the other order.
>
> Eg, given group(ctrls_toggle), LCtrl+RCtrl does next and RCtrl+LCtrl does prev.
>

More likely its something to do with left/right: I have ALT+SHIFT set as the group toggle, and I get ISO_Prev_Group regardless of the order I hold down ALT and SHIFT on the left side of the keyboard, but ISO_Next_Group regardless of the order that I hold down ALT and SHIFT on the right side of the keyboard.
Comment 45 Ilya Murav'jov 2010-02-07 14:17:20 UTC
Created attachment 33142 [details] [review]
This patch is to resolve the issue; it is for "trunk" Xorg sources.

Please try to patch Xorg from git://anongit.freedesktop.org/git/xorg/xserver
and comment if the patch works for you.
Comment 46 Nick Andrik 2010-02-07 15:34:53 UTC
Hello Ilya,

I have just used your patch towards the current Ubuntu karmic version of xorg and it works! The only "issue" was just some offsets in the file:
Applying patch 200-fix-key-pressing
patching file xkb/xkbActions.c
Hunk #1 succeeded at 385 (offset 60 lines).
Hunk #2 succeeded at 1249 (offset 86 lines).

Is it ok for you if I forward the patch also to the ubuntu bug here:
https://bugs.launchpad.net/xorg-server/+bug/36812
until it is officially included in an xserver-xorg release?

Many many thanks!
Nick
Comment 47 Nick Andrik 2010-02-07 15:37:36 UTC
Just a note, karmic's version is 1.6.4
Comment 48 Ilya Murav'jov 2010-02-07 16:01:25 UTC
(In reply to comment #46)
> Hello Ilya,
>
> Is it ok for you if I forward the patch also to the ubuntu bug here:
> https://bugs.launchpad.net/xorg-server/+bug/36812
> until it is officially included in an xserver-xorg release?
>
> Many many thanks!
> Nick
>

I forgot to note that "switch on release" is hard coded and cant be turned off.
So I am not sure it is good for wide using now. I think there will be the full solution and then ...
Comment 49 Nick Andrik 2010-02-07 16:04:51 UTC
> I forgot to note that "switch on release" is hard coded and cant be turned off.
> So I am not sure it is good for wide using now. I think there will be the full
> solution and then ...

You mean for the case that someone wants to keep the old behavior?
I may ask why to want this, but I guess the people here we are a bit biased :-P

I could propose it as a solution that can be adopted for the people to try.

Thanks again!

Comment 50 Ilya Murav'jov 2010-02-07 16:14:17 UTC
(In reply to comment #49)
>
> You mean for the case that someone wants to keep the old behavior?
> I may ask why to want this, but I guess the people here we are a bit biased :-P
>
> I could propose it as a solution that can be adopted for the people to try.
>
> Thanks again!
>

Yes, I mean that.
You're welcome.
Comment 51 Oded Arbel 2010-02-10 09:54:56 UTC
I've installed this patch on Ubuntu 9.10, Ubuntu 10.04 (alpha) and Fedora 12. On all these the patch works great and I see no problems for my use - which is granted not overly complex: two keyboard layouts with ALT+SHIFT to switch and I'm using a lot of keyboard shortcuts in many applications.
Comment 52 Alon Bar-Lev 2010-02-10 11:21:18 UTC
WORKING!
xorg-server-1.6.5

Thank you so much Ilya!
Comment 53 Mike 2010-02-13 08:40:01 UTC
just tested in kubuntu 9.1 using packages from PPA's: works just as I want it to work, so I am able to use eclipse IDE hotkeys, and that will not cause undesired layout change.

Thanks!
Comment 54 E 2010-02-15 06:29:26 UTC
Thank you!

How can I test this on my Ubuntu laptop? Is it packed in some packages or I need to compile it manually?
Can you provide an instruction, please?
Comment 55 Nick Andrik 2010-02-15 07:09:23 UTC
(In reply to comment #54)
> Thank you!
>
> How can I test this on my Ubuntu laptop? Is it packed in some packages or I
> need to compile it manually?
> Can you provide an instruction, please?
>

Take a look here:
https://bugs.launchpad.net/xorg-server/+bug/36812
Comment 56 Ori Avtalion 2010-03-22 14:08:41 UTC
Excuse me in advance if I don't use xkb terminology. :)

Shouldn't the fix be more generic, and apply to all "modifier" keys (such as ctrl, shift, alt, super) and not just layout/group switching actions?

For example, I want to be able to map the Super key to an action (which is currently impossible, AFAIK).

The logic should be something like this:

on key release:
   if the released key was a modifier, and all the pressed keys are modifiers:
       Fire the event
Comment 57 Ilya Murav'jov 2010-03-22 14:36:28 UTC
(In reply to comment #56)
> Shouldn't the fix be more generic, and apply to all "modifier" keys (such as
> ctrl, shift, alt, super) and not just layout/group switching actions?
>
> For example, I want to be able to map the Super key to an action (which is
> currently impossible, AFAIK).
>
> The logic should be something like this:
>
> on key release:
>    if the released key was a modifier, and all the pressed keys are modifiers:
>        Fire the event
>
XKB deals with concrete, well known "actions", only. What event do you want to fire with Super?
Comment 58 Ori Avtalion 2010-03-22 16:19:47 UTC
(In reply to comment #57)
> XKB deals with concrete, well known "actions", only. What event do you want to
> fire with Super?
>

I was thinking of the functionality in gnome-keybinding-properties. I thought its shortcomings were due to xkb, but apparently I was wrong :)
Comment 59 Daniel Stone 2010-03-25 20:35:59 UTC
On Sun, Feb 07, 2010 at 02:17:25PM -0800, bugzilla-daemon@freedesktop.org wrote:
> --- Comment #45 from Ilya Murav'jov <muravev@yandex.ru>  2010-02-07 14:17:20 PST ---
> Created an attachment (id=33142)
>  --> (http://bugs.freedesktop.org/attachment.cgi?id=33142)
> This patch is to resolve the issue; it is for "trunk" Xorg sources.
>
> Please try to patch Xorg from git://anongit.freedesktop.org/git/xorg/xserver
> and comment if the patch works for you.

The patch looks pretty much fine to me, except that I'd just hardcode
release-only and don't try to make it configurable.  I'm not entirely
sure about the bit marked with KLUDGE, and would like to find a better
way to do it, but if that's fixed (I'll try to have a look this weekend
or next, depending on time), my only objection to merging it is that it
explicitly contradicts the spec.  I'm not entirely convinced that's a
dealbreaker though.
Comment 60 Paulo Zanoni 2010-04-29 12:43:05 UTC
Ping? No new patch versions? Will this be applied?
Comment 61 Alexander Pavlov 2010-05-05 08:58:17 UTC
The patch works like a charm for me Ubuntu Karmic, 9.10. Daniel please do apply it. It makes a broken thing (shortcuts) work for multilingual users and doesn't harm others.
Comment 62 Ilya Murav'jov 2010-05-12 14:38:34 UTC
I've found something wrong with the patch: the keyboard starts to type capital letters with no Shift and CapsLock after changing the layout (Ctrl+Shift). That behaviour cant be always reproduced. Like so:
яzЯzяZЯzzяzяZяzЯzяZяzяzяzяzяZя

Not good ...
Comment 63 Ethan Shalev 2010-07-04 16:52:34 UTC
(In reply to comment #62)
> I've found something wrong with the patch: the keyboard starts to type capital
> letters with no Shift and CapsLock after changing the layout (Ctrl+Shift). That
> behaviour cant be always reproduced. Like so:
> яzЯzяZЯzzяzяZяzЯzяZяzяzяzяzяZя
>
> Not good ...

Have you managed to solve this? or discover a pattern, like under what circumstances this occurs?
If it doesn't happen too often, I'd be in favor of rolling out this patch, and closing this bug before it enters its 7th year.
Comment 64 Ilya Murav'jov 2010-07-05 11:41:51 UTC
(In reply to comment #63)
> (In reply to comment #62)
> > I've found something wrong with the patch: the keyboard starts to type capital
> > letters with no Shift and CapsLock after changing the layout (Ctrl+Shift). That
> > behaviour cant be always reproduced. Like so:
> > яzЯzяZЯzzяzяZяzЯzяZяzяzяzяzяZя
> >
> > Not good ...
>
> Have you managed to solve this? or discover a pattern, like under what
> circumstances this occurs?
> If it doesn't happen too often, I'd be in favor of rolling out this patch, and
> closing this bug before it enters its 7th year.

No. Unfortunately, it is difficult to get rid of it:
- much worse repeatable under debug
- it is repeatable only on my working machine, not one I use for debugging Xorg (notebook)

At first everything was fine until I started playing with keyboard settings (gnome-keyboard-properties -> Layouts -> Layout Options). Wait a minute ... Ahhhh, things go wrong if "Use keyboard LED to show alternative layout"->ScrollLock is on! That is why I couldn't reproduce it on my notebook (it doesn't have keyboard LEDs). Mmm, it is much better now :)

As for the patch, you can use Oded Arbel' repository to try it without building
Xorg yourself, http://launchpad.net/~oded-geek/+archive/xorg-patches .

P.S. I am not a developer of Xorg so I could not commit anything. On the other hand, the devs seems to be not interested too. nobody cares :(
Comment 65 Vasa Maximov 2010-07-12 15:31:57 UTC
Ilya, SPASIBO for the patch and hint with http://launchpad.net/~oded-geek/+archive/xorg-patches

Patch works perfectly - no side effects, everything goes as expected on Ubuntu 10.04

For me keyboard shortcuts are vital, and I've been waiting for this fix since 2001 - when i first met linux. Thank you VERY much!
Comment 66 kyak 2010-08-30 11:28:38 UTC
Applied the patch to xorg-server-1.7.7 (Mandriva 2010.1). Works as a charm. Looking forward to having this patch upstream.
Comment 67 Nick Andrik 2010-10-12 12:17:30 UTC
Ilya, did you debug the problem with the led as you described in #64?

Also, Daniel (the responsible for the patches to get accepted if I understood correctly) raised some concerns on #59. Do you think you could address them? I believe after that the patch will get accepted.

What do you think?

Thanks a lot for you contribution
Nick
Comment 68 Ilya Murav'jov 2010-10-12 12:43:55 UTC
(In reply to comment #67)
> Ilya, did you debug the problem with the led as you described in #64?
>
> Also, Daniel (the responsible for the patches to get accepted if I understood
> correctly) raised some concerns on #59. Do you think you could address them? I
> believe after that the patch will get accepted.
>
> What do you think?
>

I didn't debug #64; I don't see something wrong with #59.

I think the opposite,- as I understand from a few conversations Daniel do not accept the patch because of some policy. So improvements don't make sense, and I am somewhat disappointed.
Comment 69 Vasa Maximov 2010-10-12 15:10:46 UTC
(In reply to comment #67)
> Ilya, did you debug the problem with the led as you described in #64?

As for #64: I have used this gnome setting (ScrollLock to indicate layout) all the time since comment #65 and haven't experienced any issues. Except minor: scrollLock key is not able to control ScrollLock LED (who even cares?). I can't remember how it worked before patch, but pretty sure - that's Gnome behavior.
Comment 70 Nick Andrik 2010-10-12 15:16:30 UTC
I believe scrollLock LED is used from gnome(?) to indicate the alternative layout.
At least this is how it works on me with the ubuntu xorg (without the patch from ilya)
Comment 71 Nick Andrik 2010-10-14 20:44:20 UTC
After Vasa, comment I made some exploration of the scroll lock issue and in both cases (patched X or unpatched X) the behavior is exactly the same.

The led can be used to indicate the alternative layout (from gnome's settings) and it works as advertised: it switches on/off as long as the layout changes.

Even if the above functionality is disabled, still the Scroll Lock key makes no difference in gnome. I suspect that scroll lock mode never gets enabled.
I tested it in virtual consoles (Ctrl+Alt+F1) and it works like Ctrl+S (pause any console output), while in gnome (tested in xterm and gnome-terminal) the scroll lock key does absolutely nothing.


Daniel, is there anything else needed for the patch to get accepted in the official branch?


Thanks a lot.
Nick
Comment 72 Nick Andrik 2010-10-14 20:45:05 UTC
After Vasa's comment, I made some exploration of the scroll lock issue and in both cases (patched X or unpatched X) the behavior is exactly the same.

The led can be used to indicate the alternative layout (from gnome's settings) and it works as advertised: it switches on/off as long as the layout changes.

Even if the above functionality is disabled, still the Scroll Lock key makes no difference in gnome. I suspect that scroll lock mode never gets enabled.
I tested it in virtual consoles (Ctrl+Alt+F1) and it works like Ctrl+S (pause any console output), while in gnome (tested in xterm and gnome-terminal) the scroll lock key does absolutely nothing.


Daniel, is there anything else needed for the patch to get accepted in the official branch?


Thanks a lot.
Nick
Comment 73 Alexander Kojevnikov 2010-10-15 19:05:46 UTC
Just to confirm that Ilya's patch from comment 45 completely fixes the problem without any noticeable side-effects. I'm running  X11R7.5 under FreeBSD 8.1

Daniel, could you review and eventually commit the patch? This bug is quite annoying.

Thank you!
Comment 74 Dave Walker 2010-12-03 03:32:59 UTC
Hi,

Is there an update on the status of this bug please?

Kind Regards,
Dave Walker
Comment 75 Simos Xenitellis 2010-12-03 08:39:30 UTC
(In reply to comment #74)
> Hi,
>
> Is there an update on the status of this bug please?
>

My guess is that this bug is stuck at the point where the patch needs extensive and explicit testing.

Some users tested this on their system, however they should to come up with a more rigorous description of what they have tested.

Things to test would include
1. Describe which shortcut you use to switch layouts (Alt+Shift, Shift+Shift, etc)
2. Mention outcome when using with Firefox, OpenOffice, Inkscape, some GTK+ and QT apps.
3. Is there any problem when using IBus? Check the shortcuts that activate/deactivate/switch layout in IBus.
4. how long you have been using your Linux with this patch applied.
5. GTK+ allows to type arbitrary Unicode characters with Ctrl+Shift+u <HEX codepoint>. Does this continue to work?
6. An important test case is to use Inkscape and switch layouts with Alt+Shift. Presumably, Alt+Shift+xyz is a type of valid shortcuts in Inkscape, and affected by this bug. Is this now solved?
Comment 76 kyak 2010-12-04 08:40:00 UTC
(In reply to comment #75)
> (In reply to comment #74)
> > Hi,
> >
> > Is there an update on the status of this bug please?
> >
>
> My guess is that this bug is stuck at the point where the patch needs extensive
> and explicit testing.
>
> Some users tested this on their system, however they should to come up with a
> more rigorous description of what they have tested.
>
> Things to test would include
> 1. Describe which shortcut you use to switch layouts (Alt+Shift, Shift+Shift,
> etc)
> 2. Mention outcome when using with Firefox, OpenOffice, Inkscape, some GTK+ and
> QT apps.
> 3. Is there any problem when using IBus? Check the shortcuts that
> activate/deactivate/switch layout in IBus.
> 4. how long you have been using your Linux with this patch applied.
> 5. GTK+ allows to type arbitrary Unicode characters with Ctrl+Shift+u <HEX
> codepoint>. Does this continue to work?
> 6. An important test case is to use Inkscape and switch layouts with Alt+Shift.
> Presumably, Alt+Shift+xyz is a type of valid shortcuts in Inkscape, and
> affected by this bug. Is this now solved?

I guess most people are just satisfied with this patch, which, obviously, works great. Therefore nobody really cares if it would go upstream or not, because, obviously, it won't (otherwise, tell me, how much longer it should take to accept this patch?).

Also, the "things to test would include" items look like the author hasn't even tested the patch, otherwise, he wouldn't have any of those concerns.

Thank you.
Comment 77 Alexander Kojevnikov 2010-12-04 18:23:33 UTC
(In reply to comment #76)
> I guess most people are just satisfied with this patch, which, obviously, works
> great.

It does indeed, just look as the number of comments confirming it.

> Also, the "things to test would include" items look like the author hasn't even
> tested the patch, otherwise, he wouldn't have any of those concerns.

I went ahead and did the tests grandfather mentioned:

(In reply to comment #75)
> 1. Describe which shortcut you use to switch layouts (Alt+Shift, Shift+Shift,
> etc)

Alt+Shift, I guess that's what most people use (it's a Windows default too)

> 2. Mention outcome when using with Firefox, OpenOffice, Inkscape, some GTK+ and
> QT apps.

No issues whatsoever. Tested it on ArchLinux and on FreeBSD.

> 3. Is there any problem when using IBus? Check the shortcuts that
> activate/deactivate/switch layout in IBus.

Is it for CJK input? Never used it.

> 4. how long you have been using your Linux with this patch applied.

Linux almost since this patch has been submitted, FreeBSD - for 3 months.

> 5. GTK+ allows to type arbitrary Unicode characters with Ctrl+Shift+u <HEX
> codepoint>. Does this continue to work?

Yes: ☺ ♫ ⊥

> 6. An important test case is to use Inkscape and switch layouts with Alt+Shift.
> Presumably, Alt+Shift+xyz is a type of valid shortcuts in Inkscape, and
> affected by this bug. Is this now solved?

Yes, also some Emacs shortcuts were affected by this bug (e.g. M-> and M-<) and now work fine.

I really hope this patch gets committed, the keyboard input *is* broken without it for users who use multiple keyboard layouts. I personally don't mind patching xorg-server manually, but I guess most users do.
Comment 78 Oded Arbel 2010-12-05 00:16:37 UTC
(In reply to comment #75)
> Things to test would include
> 3. Is there any problem when using IBus? Check the shortcuts that
> activate/deactivate/switch layout in IBus.

Input methods may be a problem as i dont think anyone who is interested in this is using IM. I dont know why - maybe IM users dont use layout switching shortcuts, maybe they don't use shortcuts at all? But that is
A good reason to apply this patch to X.org's trunk - until that is done we cant get any serious testing of this feature as the only people that encounter the patch are the people that come looking for it specifically and all those fall into a set of well defined parameters.
Comment 79 Ilya Murav'jov 2011-01-06 16:04:59 UTC
The patch has been applied in Ubuntu, just now.
Today is a good day. :)
Comment 80 Oded Arbel 2011-01-08 05:52:26 UTC
The following comments were made by Peter Hutterer (an X.org input developer) on the corresponding bug in RedHat bugzilla ( https://bugzilla.redhat.com/show_bug.cgi?id=660254 ):
(In reply to comment #6)
> implementing this behaviour requires guesswork that I'm not sure is safe in a
> number of setups.
...
> afaict, the desired behaviour for a ctrl+shift groupchange is:
> ctrl down → set Control modifier
> shift down → set Shift modifier
> if (other key pressed)
>    send event Contrl+Shift+<other key>
> else if (ctrl || shift released)
>    change group
>
> The XKB map for left control in this case is:
>     key <LCTL> {         [       Control_L,  ISO_Next_Group ] };
> So whenever ISO_Next_Group is pressed, you still need to know which modifier to
> set in case the group action isn't executed. The XkbSA_SetMod, XkbSA_LockMod,
> etc. actions provide the modifiers set for a given key, hence why it works
> currently. This information comes from the client when the xkb map is loaded
> and is used to trigger the modifier flags for a given key. The XkbSA_LockGroup
> behaviour (which is triggered at ISO_Next_Group) does not have this field
> (adding it would break ABI), so you need to guess which modifiers to set if you
> didn't trigger this action. This is the main stumbling point that I found and
> if you look at Ilya's patch that's where he needs the big hack that I'm not
> comfortable at all with it.
>
> Now, I don't know if there are layouts where the modifier mask would be
> different on the second level as opposed to the first (and Ilya's hack or a
> similar attempt would fail completely) but there's so many layouts that it'll
> take a while to get through them all.

Ilya - this is hardly my area of expertise, so if you can address these issues - either by commenting here, on the RedHat bugzilla or by changing the patch - I would greatly appreciate that.

Thanks to all the people who are involved, and lets keep the communication channels open :-)
Comment 81 Ilya Murav'jov 2011-01-08 14:32:10 UTC
(In reply to comment #80)

Ok, I try to answer here, but I should note that I don't remember full details
(because it was more than half a year ago).

> The following comments were made by Peter Hutterer (an X.org input developer)
> on the corresponding bug in RedHat bugzilla (
> https://bugzilla.redhat.com/show_bug.cgi?id=660254 ):
> (In reply to comment #6)
> > implementing this behaviour requires guesswork that I'm not sure is safe in a
> > number of setups.
> ...
> > afaict, the desired behaviour for a ctrl+shift groupchange is:
> > ctrl down → set Control modifier
> > shift down → set Shift modifier
> > if (other key pressed)
> >    send event Contrl+Shift+<other key>
> > else if (ctrl || shift released)
> >    change group
> >
> > The XKB map for left control in this case is:
> >     key <LCTL> {         [       Control_L,  ISO_Next_Group ] };
> > So whenever ISO_Next_Group is pressed, you still need to know which modifier to
> > set in case the group action isn't executed. The XkbSA_SetMod, XkbSA_LockMod,
> > etc. actions provide the modifiers set for a given key, hence why it works
> > currently. This information comes from the client when the xkb map is loaded
> > and is used to trigger the modifier flags for a given key. The XkbSA_LockGroup
> > behaviour (which is triggered at ISO_Next_Group) does not have this field
> > (adding it would break ABI), so you need to guess which modifiers to set if you
> > didn't trigger this action. This is the main stumbling point that I found and
> > if you look at Ilya's patch that's where he needs the big hack that I'm not
> > comfortable at all with it.

I do not agree. You do not need to know/guess which modifiers to set - whenever
ISO_Next_Group is pressed I just don't execute it immediately but delay it till a key release (by the means of _XkbNextFreeFilter()/_XkbApplyFilters() ). Btw, that trick was suggested by Daniel Stone (somewhere on the mail list).

And I want to note that where I comment ":KLUDGE:" I mean a different thing: in theory that branch of code should do the same thing as the switch in XkbHandleActions() ; but, in practice I see (and want) only XkbSA_SetMods action (so kludge here is copy-n-paste from XkbHandleActions() ).

> >
> > Now, I don't know if there are layouts where the modifier mask would be
> > different on the second level as opposed to the first (and Ilya's hack or a
> > similar attempt would fail completely) but there's so many layouts that it'll
> > take a while to get through them all.

(do not understand properly the above, sorry) The only situation the patch fails
(just behaves old way, and nothing more!) is when switching is set up as just one key like "Right Alt". That is because of the line
   fake_state.mods = 0;
, mods here is 0 anyway => we can't block XkbSA_LockGroup .

Anyway, nobody wants more,- but only (de facto standard) Ctrl+Shift and Alt+Shift on release. I think this is the situation where the practice begins and the theory ends.
Comment 82 Artem S. Tashkinov 2011-04-07 12:31:45 UTC
I'm confused. This bug is now 7 years old and it's still not fixed? What year of desktop Linux are we talking about when basic things in Linux are largely broken?
Comment 83 Peter Hutterer 2011-04-07 16:15:42 UTC
(In reply to comment #82)
> I'm confused. This bug is now 7 years old and it's still not fixed? What year
> of desktop Linux are we talking about when basic things in Linux are largely
> broken?

thanks. empty rhetoric is the greatest way of motivating developers. This bug just dropped to the bottom of my priority list again.
Comment 84 Artem S. Tashkinov 2011-04-07 23:59:18 UTC
(In reply to comment #83)
> thanks. empty rhetoric is the greatest way of motivating developers. This bug
> just dropped to the bottom of my priority list again.

Peter, I'm terribly sorry for rending the air. Please, consider resolving this bug ASAP since there are thousands of people affected by it. I won't drop another comment here ever.
Comment 85 kyak 2011-04-08 01:05:27 UTC
(In reply to comment #84)
> (In reply to comment #83)
> > thanks. empty rhetoric is the greatest way of motivating developers. This bug
> > just dropped to the bottom of my priority list again.
>
> Peter, I'm terribly sorry for rending the air. Please, consider resolving this
> bug ASAP since there are thousands of people affected by it. I won't drop
> another comment here ever.

You don't have to excuse. You have more rights to be pissed off than a developer who puts an obvious and already proved (by time) to work patch to the end of his TODO list.
Comment 86 Daniel Stone 2011-04-08 03:13:41 UTC
On Fri, Apr 08, 2011 at 01:05:34AM -0700, bugzilla-daemon@freedesktop.org wrote:
> --- Comment #85 from kyak <bas@bmail.ru> 2011-04-08 01:05:27 PDT ---
> (In reply to comment #84)
> > (In reply to comment #83)
> > > thanks. empty rhetoric is the greatest way of motivating developers. This bug
> > > just dropped to the bottom of my priority list again.
> >
> > Peter, I'm terribly sorry for rending the air. Please, consider resolving this
> > bug ASAP since there are thousands of people affected by it. I won't drop
> > another comment here ever.
>
> You don't have to excuse. You have more rights to be pissed off than a
> developer who puts an obvious and already proved (by time) to work patch to the
> end of his TODO list.

Already proven to break the XKB specification, yes.
Comment 87 Dmitry 2011-04-08 12:52:19 UTC
Can we pay to speed up the fixing of this bug?
Comment 88 Oded Arbel 2011-04-08 13:10:46 UTC
(In reply to comment #86)
> Already proven to break the XKB specification, yes.

Hi Daniel. I've seen this comment about breaking the XKB specification in several places and - I'm really not trying to be contrary - I looked at the protocol specs here http://www.x.org/releases/current/doc/kbproto/xkbproto.html and I can't understand how this behavior change contradicts the spec.

Now - I'm not a trained X11 developer, and I'm not even that good at reading specs, so I would really appreciate it if you can point me at the section relevant to the breakage you discuss, so I can be more informed about the issue.

Thanks in advance.
Comment 89 Artem S. Tashkinov 2011-04-08 13:18:04 UTC
(In reply to comment #87)
> Can we pay to speed up the fixing of this bug?

I second this motion.
Comment 90 Ilya Murav'jov 2011-04-11 08:40:34 UTC
(In reply to comment #88)
> (In reply to comment #86)
> > Already proven to break the XKB specification, yes.
>
> Hi Daniel. I've seen this comment about breaking the XKB specification in
> several places and - I'm really not trying to be contrary - I looked at the
> protocol specs here http://www.x.org/releases/current/doc/kbproto/xkbproto.html
> and I can't understand how this behavior change contradicts the spec.
>
> Now - I'm not a trained X11 developer, and I'm not even that good at reading
> specs, so I would really appreciate it if you can point me at the section
> relevant to the breakage you discuss, so I can be more informed about the
> issue.
>
> Thanks in advance.

Hi Oded,

It is not in XKBproto but in XKBlib spec. You can see the only assertion against changing layout on release in general (and the patch in particular) in ftp://ftp.x.org/pub/X11R7.0/doc/PDF/XKBlib.pdf, "Table 16.4 Group Action Types", the last item XkbSA_LockGroup, citing:

"
1. If the XkbSA_GroupAbsolute is set in the flags field, key press events set the locked keyboard group to the group specified by the group_XXX field. Otherwise, key press events add the group specified by the group_XXX field to the locked keyboard group. In either case, the resulting locked and effective keyboard groups are brought back into range depending on the value of the groups_wrap field of the con-trols structure.
2. A key release has no effect.
"
Comment 91 Michal Ambroz 2011-04-18 11:58:35 UTC
I would vote for this change as well.

I understand that it is not aligned with 13 years old standard and I am sorry for that. Still I see changing group on press breaking much many things than changing it on release. Maybe it is time to modify this library specification, because there is a good reason for that. Do you see any reason not to do it - other than there exists 13 years old library specification?

Best regards
Michal Ambroz
Comment 92 youagree 2011-08-22 07:14:34 UTC
For Gentoo and derivatives users, a working solution for patching is described here:

https://bugs.gentoo.org/show_bug.cgi?id=379827

Bug report description includes guidance for how an ebuild file for automatic patching of XkbActions.c can be achieved, and an example ebuild file that applies Ilya's patch to Gentoo version of xorg-server-1.10.3 as attachment is also provided by Lance Poore.

I am using the patched version happily now without having any problems. Please consider including the patch in upstream. I am sure it would make thousands of desktop Linux users' lives easier.

Thanks Ilya! and thanks to Lance in the name of Gentoo Linux multilingual keyboard users.
Happy patching :)
Comment 93 Alon Bar-Lev 2011-08-22 07:21:31 UTC
Long ago a bug was opened for this issue.

https://bugs.gentoo.org/show_bug.cgi?id=304375

On Mon, Aug 22, 2011 at 5:14 PM,  <bugzilla-daemon@freedesktop.org> wrote:
> https://bugs.freedesktop.org/show_bug.cgi?id=865
>
> --- Comment #92 from youagree <n3ocort3x@gmail.com> 2011-08-22 07:14:34 PDT ---
> For Gentoo and derivatives users, a working solution for patching is described
> here:
>
> https://bugs.gentoo.org/show_bug.cgi?id=379827
>
> Bug report description includes guidance for how an ebuild file for automatic
> patching of XkbActions.c can be achieved, and an example ebuild file that
> applies Ilya's patch to Gentoo version of xorg-server-1.10.3 as attachment is
> also provided by Lance Poore.
>
> I am using the patched version happily now without having any problems. Please
> consider including the patch in upstream. I am sure it would make thousands of
> desktop Linux users' lives easier.
>
> Thanks Ilya! and thanks to Lance in the name of Gentoo Linux multilingual
> keyboard users.
> Happy patching :)
>
> --
> Configure bugmail: https://bugs.freedesktop.org/userprefs.cgi?tab=email
> ------- You are receiving this mail because: -------
> You are on the CC list for the bug.
>
Comment 94 youagree 2011-08-22 13:04:17 UTC
(In reply to comment #93)
> Long ago a bug was opened for this issue.
>
> https://bugs.gentoo.org/show_bug.cgi?id=304375
>

And marked as "resolved upstream". Which is just not true, at least according to the ebuilds. Havent taken a look at the code itself, but can you currently point to any existing xorg source repository with the patch applied or where xorg server has the same functionality issue cured?

Thanks
Comment 95 Jeremy Huddleston 2011-09-25 16:12:17 UTC
Lots of CCs ... I'm gonna bring this into the tracker to see if there's
something we can eventually do about this in a way that won't break backwards
compatibility.

Daniel, do you have any thoughts about how this could be done by extending XKB
rather than breaking it?
Comment 96 Amnon Harel 2011-12-25 23:54:41 UTC
(In reply to comment #90)
> (In reply to comment #88)
> > (In reply to comment #86)
> > > Already proven to break the XKB specification, yes.
> > ...
>
> It is not in XKBproto but in XKBlib spec. You can see the only assertion
> against changing layout on release in general (and the patch in particular) in
> ftp://ftp.x.org/pub/X11R7.0/doc/PDF/XKBlib.pdf, "Table 16.4 Group Action
> Types", the last item XkbSA_LockGroup, citing:
>
> "
> 1. If the XkbSA_GroupAbsolute is set in the flags field, key press events set
> ....
> 2. A key release has no effect.
> "
Thanks again Ilya!
First for providing the patch, and then for high-lighting exactly where the XKB standard made what we now know to be a bad choice. Happens. No one's perfect. Not even the wisdom of the Xfree86 crowd.
Anyone know whether / how the standard can be brought up to date, so it joins us in the new millennium?
Comment 97 Jeremy Huddleston 2011-12-27 21:57:31 UTC
Deferring to 1.13 as this is functional change
Comment 98 kyak 2012-04-01 11:04:34 UTC
The patch doesn't apply anymore to latest xorg. Could someone update it, please?

I tried to just blindly port this patch, but it seems to cause problems with Caps Lock (it can't be switched off once switched on). So something has changed.

Could someone with xorg knowledge have a look please?
Comment 99 kyak 2012-04-10 10:59:43 UTC
Sorry, it was my overlook. THe patch works just fine, just needed more attention adapting to latest sources.
Comment 100 kyak 2012-04-10 11:01:13 UTC
Created attachment 59741 [details] [review]
The same patch, but based on 1.12.0.902
Comment 101 Alex Efros 2012-06-03 03:16:12 UTC
While this patch solve conflict between keyboard layout switching hotkey and other hotkeys, it doesn't fix this issue in general. For example, in one have hotkey defined for Win key (a.k.a. Super_L), and for Win+something, the first hotkey handler will always run when Win key DOWN, thus pressing Win+something will result in executing both Win and Win+something handlers.

It should be fixed in same way: process current key combination on first UP event after a sequence of DOWN events, not on first DOWN.
Comment 102 Alon Bar-Lev 2012-06-23 12:55:39 UTC
Created attachment 63378 [details] [review]
xorg-server-1.12.2-xkb-switch-on-release.patch

Some code style modifications.
Comment 103 Julius Schwartzenberg 2012-08-19 15:30:36 UTC
This patch breaks the keyboard layout switcher from KDE3 and Trinity. It works correctly with the layout switcher in KDE4. Have other people tested this patch with other layout switchers? What are the results?
Comment 104 Oded Arbel 2012-08-24 08:24:05 UTC
(In reply to comment #103)
> This patch breaks the keyboard layout switcher from KDE3 and Trinity. It works
> correctly with the layout switcher in KDE4. Have other people tested this patch
> with other layout switchers? What are the results?

This works fine with all switchers shipped on Ubuntu (gnome, unity, kde4, etc.).
Comment 105 Murz 2012-08-27 08:06:11 UTC
Oded Arbel, how did you test this patch on Ubuntu? Can you give me some link to PPA or deb files for testing?
Comment 106 russianneuromancer 2012-08-27 10:06:58 UTC
> how did you test this patch on Ubuntu?
It's already merged. You may just install latest Ubuntu to check this patch in action. Personally I doesn't have any troubles with this patch too (KDE4, Unity).
Comment 107 Bill Spitzak 2012-10-02 19:40:01 UTC
As in comment 101, the current behavior of X prevents a lot of interesting usage of shift keys as shortcuts.

A Windows-only compose key program uses the "ctrl" key as the compose key. This is apparently impossible to do in X input methods because you can only bind actions to the press of "ctrl". What is wanted is an action if "ctrl" is pressed and released without hitting any other keys.

I think this can be solved more easily. For any "shift" key, you can bind actions to them, but they are only triggered if you press & release the shift key. All other keys trigger bound actions when they are pressed. The keyboard switching is NOT a special case.
Comment 108 kitaets 2012-10-02 20:23:48 UTC
I don't know what they have done in Ubuntu but 12.04 understands both press and release. Layout switching happens on release. If you press Alt you see the global menu and after release HUD uppears. Looks like everything has been fixed. But if you use Ctrl or Alt for layout switching you still can't use this key for anything more, it's "exclusived" :( So ridiculous.
Comment 109 Oded Arbel 2012-10-03 14:52:19 UTC
(In reply to comment #108)
> I don't know what they have done in Ubuntu but 12.04 understands both press
> and release. Layout switching happens on release.

Ubuntu have simply applied Ilya's patch (one of the revisions attached here) to fix the layout switching problem.

> If you press Alt you see
> the global menu and after release HUD uppears.

This is a different behavior and one that works with the pristine X.org server - the ALT key, when used without any other shift keys, fires "down" when pressed and "up" when released. The Ubuntu HUD listens for this sequence and triggers when ALT is used like that without any other shift key.

The problematic behavior (as documented in this lengthy bug report - kitates, please read the discussion), is that when you press down on the second shift key, X.org fires the keyboard layout change (problem 1) and also immediately fires the "up" event for the second shift key, even though the user is still holding the key down (problem 1).

Problem 1 means that when the user wants to use <shift1>+<shift2>+<key> as a keyboard shortcut (when "shift1" and "shift2" are the shift keys used for layout switching, for example ALT+SHIFT or CTRL+ALT), then the user will inadvertently also trigger a layout switching that wasn't supposed to happen.

Problem 2 means that the actual keyboard shortcut will never actually trigger because when the user holds down <key>, even though all keys are physically held down X.org only acknowledges that <shift1> and <key> are held down.

> Looks like everything has
> been fixed. But if you use Ctrl or Alt for layout switching you still can't
> use this key for anything more, it's "exclusived" :( So ridiculous.

It shouldn't work like that - I've tested the Ubuntu built X.org (with Ilya's patch) and it worked properly when using CTRL+ALT as the keyboard switching. It was immediately after the patch got accepted (at 11.04) but as ALT+SHIFT still works fine, I don't see a reason everything shouldn't continue to work (though I don't have access to an Ubuntu machine ATM to test).
Comment 110 Andreas Wettstein 2012-10-04 19:10:22 UTC
(In reply to comment #107)

> A Windows-only compose key program uses the "ctrl" key as the compose key.
> This is apparently impossible to do in X input methods because you can only
> bind actions to the press of "ctrl".

Of course this is possible. Compose is unrelated to actions in the XKB meaning of the term. It is not only possible, it is even implemented in the XIM compose code.  You can put

  <Control_L><a><e> : ae

and similar stuff in your .XCompose, and your left control key acts as a Compose key.  But you need the latest libX11 for this.
Comment 111 kyak 2012-10-14 09:55:17 UTC
I'm really disappointed this change didn't make it to 1.13.
I'm sick and tired of applying this patch after each xorg update.

How many users (and years) do you need to finally accept this change?
Comment 112 Andreas Wettstein 2012-10-14 15:17:34 UTC
I believe the most serious objection with this request is that it violates the XKB specification (see the description of SA_LockGroup in section 6.3 of "The X Keyboard Extension: Protocol Specification").

In the same specification, in section 4.0 of appendix D ("Protocol Encoding"), we see in the description of SA_LockGroup that there are still 5 unused bits in the flags field.  My proposal in to use one of these bits decide whether to lock groups on press or release.  By default (bit is zero), lock groups on press as the protocol specification demands.  If the flag is one, lock groups on release.  So by default, we would conform to the specification, and add the alternative behaviour as a new possibility beyond the specification.

There are some usage implications.  One must use 'Private' do create actions with the new flag set (until xkbcomp is updated as well), and one needs support in xkeyboard-config to make the new feature usable for non-XKB-hackers.
Comment 113 kyak 2012-10-14 16:33:59 UTC
(In reply to comment #112)
> I believe the most serious objection with this request is that it violates
> the XKB specification (see the description of SA_LockGroup in section 6.3 of
> "The X Keyboard Extension: Protocol Specification").
>
> In the same specification, in section 4.0 of appendix D ("Protocol
> Encoding"), we see in the description of SA_LockGroup that there are still 5
> unused bits in the flags field.  My proposal in to use one of these bits
> decide whether to lock groups on press or release.  By default (bit is
> zero), lock groups on press as the protocol specification demands.  If the
> flag is one, lock groups on release.  So by default, we would conform to the
> specification, and add the alternative behaviour as a new possibility beyond
> the specification.
>
> There are some usage implications.  One must use 'Private' do create actions
> with the new flag set (until xkbcomp is updated as well), and one needs
> support in xkeyboard-config to make the new feature usable for
> non-XKB-hackers.

Thanks Andreas, your answer pretty much clarifies everything for me!

Your proposal is very correct, no doubt. Does it mean that once your proposal is implemented all 3rd-party keyboard switchers (like those in Gnome and KDE) would have to be updated to make use of this new possibility?

Anyway, as i see it, there are two ways to go:
1) The long way - making things right and according to specification. This would take from very long to forever (this is the way we've been going for the last 8 years with this bug report).
2) Take a short way - let the common sense win over specification and make everybody happy.
Comment 114 Andreas Wettstein 2012-10-14 18:15:30 UTC
> Your proposal is very correct, no doubt. Does it mean that once your
> proposal is implemented all 3rd-party keyboard switchers (like those in
> Gnome and KDE) would have to be updated to make use of this new possibility?

As far as I understand, KDE and Gnome all use xkeyboard-config, and just provide their own GUI.  If this is understanding is correct, the changes to xkeyboard-config would be sufficient.

> Anyway, as i see it, there are two ways to go:
> 1) The long way - making things right and according to specification. This
> would take from very long to forever (this is the way we've been going for
> the last 8 years with this bug report).

Assuming the existing patch is correct, adding the additional check for the flag is just a few lines.  The changes to xkeyboard-config would be fairly simple.  Assuming we grab bit 3 for the new flag, in xkeyboard-config/compat/iso9995, change the current definition:

  interpret ISO_Next_Group {
      useModMapMods= level1;
      virtualModifier= AltGr;
      action= LockGroup(group=+1);
  }

to

  interpret ISO_Next_Group {
      useModMapMods= level1;
      virtualModifier= AltGr;
      action= Private(type=6, data[0]=16, data[1]=1);
  }

(untested, of course), and similarly for ISO_Prev_Group, ISO_First_Group, and ISO_Last_Group.  I do not know wether the action bound to keysyms is standardised; even if it is not, it might be a good idea to make the above redefinition conditional.

> 2) Take a short way - let the common sense win over specification and make
> everybody happy.

Believe it or not, I would be unhappy when the specification would be broken.  Also  remember that the attitudes in this discussion are not necessarily representative of all X users, as the users satisfied with the current behaviour do not have any reason to even know about this discussion.
Comment 115 kitaets 2012-10-17 18:54:28 UTC
(In reply to comment #109)
> (In reply to comment #108)
> > Looks like everything has
> > been fixed. But if you use Ctrl or Alt for layout switching you still can't
> > use this key for anything more, it's "exclusived" :( So ridiculous.
>
> It shouldn't work like that - I've tested the Ubuntu built X.org (with
> Ilya's patch) and it worked properly when using CTRL+ALT as the keyboard
> switching. It was immediately after the patch got accepted (at 11.04) but as
> ALT+SHIFT still works fine, I don't see a reason everything shouldn't
> continue to work (though I don't have access to an Ubuntu machine ATM to
> test).

Oded Arbel, I repeat: Ctrl OR Alt. OR, not AND. I use right Alt for layout switching so I can't use it for any other purpose.
Comment 116 Ilya Murav'jov 2012-10-28 14:55:03 UTC
(In reply to comment #115)
> > It shouldn't work like that - I've tested the Ubuntu built X.org (with
> > Ilya's patch) and it worked properly when using CTRL+ALT as the keyboard
> > switching. It was immediately after the patch got accepted (at 11.04) but as
> > ALT+SHIFT still works fine, I don't see a reason everything shouldn't
> > continue to work (though I don't have access to an Ubuntu machine ATM to
> > test).
>
> Oded Arbel, I repeat: Ctrl OR Alt. OR, not AND. I use right Alt for layout
> switching so I can't use it for any other purpose.

Hi,
Actually, the patch works for key shortcuts with two or more buttons (like ALT+SHIFT, but not Alt or Ctrl alone). It is not done intentionally.

Despite the fact that there is a possibility to improve current patch behaviour for needs like yours I don't think it should be improved for all possible cases -
there are many other things to be done to make the world a better place.
Comment 117 Andreas Wettstein 2012-10-28 16:37:40 UTC
Created attachment 69198 [details] [review]
LockMods can lock another group

This patch follows a different route: It extends modifier locking, rather than changing how group lock works. Extending has the advantage that the previous behaviour is maintained, and the patch does not violate the X Keyboard Protocol Specification.  Extending modifier locking rather than group locking has the advantage that we do not need the "Kludge" of the other patch, as we can pass the modifiers that we want to set, rather then relying on heuristics.

The disadvantage over the existing patch is that we must change the keymap.

Here are three examples.  The left alt key is to switch to the next layout when it is pressed and released before any other key is pressed.

    key <LALT> {
        repeat= No,
        type= "TWO_LEVEL",
        symbols[Group1]= [           Alt_L,          Meta_L ],
	actions[Group1]= [ Private(type=3,data[0]=1,data[1]=8,data[2]=8,data[3]=0,data[4]=0,data[5]=0,data[6]=1),
	                   Private(type=3,data[0]=1,data[1]=8,data[2]=8,data[3]=0,data[4]=0,data[5]=0,data[6]=1) ]
    };

Similarly, shifting group with Shift+Right Alt (where Shift is pressed first):
Comment 118 Andreas Wettstein 2012-10-28 16:39:09 UTC
Similarly, shifting group with Shift+Right Alt (where Shift is pressed first):

  key <RALT> {
        repeat= No,
        type= "TWO_LEVEL",
        symbols[Group1]= [           Alt_R,          Meta_R ],
	actions[Group1]= [ SetMods(modifiers=Mod1),
	                   Private(type=3,data[0]=1,data[1]=8,data[2]=8,data[3]=0,data[4]=0,data[5]=0,data[6]=1) ]
    };

Shifting group with Shift+Left Control:


    key <LCTL> {
        repeat= No,
        type= "TWO_LEVEL",
        symbols[Group1]= [           Control_L,          Control_L ],
	actions[Group1]= [ SetMods(modifiers=Control),
	                   Private(type=3,data[0]=1,data[1]=4,data[2]=4,data[3]=0,data[4]=0,data[5]=0,data[6]=1) ]
    };
Comment 119 Alex Efros 2012-10-28 17:06:28 UTC
(In reply to comment #117)
> Similarly, shifting group with Shift+Right Alt (where Shift is pressed first):

Is this mean your patch won't work when Alt (or Ctrl) is pressed before Shift?
AFAIK most people press Ctrl, then Shift, then either release them (to switch layout) or press A-Z when they need Ctrl-Shift-something hotkey.
Comment 120 Andreas Wettstein 2012-10-28 17:49:19 UTC
> Is this mean your patch won't work when Alt (or Ctrl) is pressed before
> Shift?

It does not mean that.  I just restricted to three examples.  There is no problem to rewrite all options that xkeyboard-config offers to switch groups to take advantage of the patch.

> AFAIK most people press Ctrl, then Shift, then either release them (to
> switch layout) or press A-Z when they need Ctrl-Shift-something hotkey.

In this case, one needs to remap the shift key. For the left shift key:

    key <LFSH> {
        repeat= No,
        type[Group1]="PC_CONTROL_LEVEL2",
        symbols[Group1]= [ Shift_L, Shift_L ],
	actions[Group1]= [ SetMods(modifiers=Shift),
	                   Private(type=3,data[0]=1,data[1]=1,data[2]=1,data[3]=0,data[4]=0,data[5]=0,data[6]=1) ]
    };

For the right shift key it works similarly. If combined with the third example above, it will make the order of Shift and Control irrelevant.
Comment 121 Andreas Wettstein 2012-10-29 08:43:43 UTC
Created attachment 69213 [details] [review]
LockMods can lock another group

My previous patch does not properly account for absolute group specification. The revised patch corrects this.
Comment 122 Nick Andrik 2012-11-02 02:36:20 UTC
Just to add something as a reply on comment #114:

Ubuntu has applied this patch already since 06 Jan 2011 all versions till nowadays, as you can see in the changelogs here:

http://packages.ubuntu.com/quantal/xserver-xorg-core
Select "Ubuntu Changellog" and then search for "208_switch_on_release.diff".

Even after almost two years, there has been noone to file a bug report that this change breaks anything. I believe this is quite a good indication that Ilya's patch is already safe enough.
Comment 123 Someone like you 2013-04-11 06:57:56 UTC
It is xorg-server 1.14, year 2013, and the bug still exists.

Do something with it already...
Comment 124 Eugene Shalygin 2013-04-11 13:15:51 UTC
I wonder, bearing in mind the fact that Ubuntu has the patch for the problem, will Mir be the first Linux display server which implemet this feature? :)
Comment 125 Artem S. Tashkinov 2013-04-11 13:35:18 UTC
(In reply to comment #124)
> I wonder, bearing in mind the fact that Ubuntu has the patch for the
> problem, will Mir be the first Linux display server which implement this
> feature? :)

You've wandered far off.

Both Mir and Wayland have a completely different input architecture - they simply don't have this problem from the very beginning.
Comment 126 headcrabextra 2013-04-28 19:53:26 UTC
I've just installed OpenSuse 12.3 and met face to face with this bug. Very frustrating, because of it I can't open last closed tab in chromium with ctrl+shift+t.
Comment 127 Igor Gnatenko 2014-02-03 07:17:57 UTC
any news here?
Comment 128 Murz 2014-02-03 07:19:53 UTC
Igor Gnatenko, I partly solve my problem via KSuperKey app http://kde-apps.org/content/show.php?content=154569
so maybe it solve your needs too.

But I also waiting fix for this issue in xkb.
Comment 129 Adam Purkrt 2014-09-06 20:30:17 UTC
As far as I can tell, it is already clear that XKB specifications needs to be extended for this to be cleanly solved. While Ilya's hack works for many people, and as much as I would like to see this fixed, I understand why it is unacceptable to the developers. So, trying to delve into XKB specs now; this page seems to be a good starting point to me:

https://wiki.archlinux.org/index.php/X_KeyBoard_extension


Also (as suggested by the author), copying info here from https://bugzilla.redhat.com/show_bug.cgi?id=660254


Peter Hutterer 2011-01-05 22:07:57 EST

there is two problems with the "tiny" patch you mentioned. one, it's an _explicit_ violation of the XKB specification (see section 4.4). two, implementing this behaviour requires guesswork that I'm not sure is safe in a number of setups.


Peter Hutterer 2011-01-06 17:12:05 EST

(In reply to comment #4)
> But: doesn't fixing of a huge problem have a priority over preservation of a
> "holy spec"?

it's a matter of figuring out the side-effects. a specification is a behaviour promise, in this case in place for 15 years or so. a lot of users and apps rely on the promised behaviour (in general, not necessarily this specific issue) and breaking it is a dangerous thing because you may not know what else you break.
this is why we're hesitant to break the behaviour on purpose.

note that i'm not claiming that there is no problem, i'm just saying it's the balance between a known problem and introducing new bugs that potentially break current applications.

> > two,
> > implementing this behaviour requires guesswork that I'm not sure is safe in a
> > number of setups.
>
> What guesswork do you mean?  Which setups can present problems?
> BTW, I'm 100% sure that Ilya Murav'jev (patch author) will be glad to
> cooperate.

afaict, the desired behaviour for a ctrl+shift groupchange is:
ctrl down → set Control modifier
shift down → set Shift modifier
if (other key pressed)
   send event Contrl+Shift+<other key>
else if (ctrl || shift released)
   change group

The XKB map for left control in this case is:
    key <LCTL> {         [       Control_L,  ISO_Next_Group ] };
So whenever ISO_Next_Group is pressed, you still need to know which modifier to set in case the group action isn't executed. The XkbSA_SetMod, XkbSA_LockMod, etc. actions provide the modifiers set for a given key, hence why it works currently. This information comes from the client when the xkb map is loaded and is used to trigger the modifier flags for a given key. The XkbSA_LockGroup behaviour (which is triggered at ISO_Next_Group) does not have this field (adding it would break ABI), so you need to guess which modifiers to set if you didn't trigger this action. This is the main stumbling point that I found and if you look at Ilya's patch that's where he needs the big hack that I'm not comfortable at all with it.

Now, I don't know if there are layouts where the modifier mask would be different on the second level as opposed to the first (and Ilya's hack or a similar attempt would fail completely) but there's so many layouts that it'll take a while to get through them all.

> And leaving the design bug because of purist reason looks really strange...

there's two-ish ppl working on input at them moment, both are badly overloaded because there's a lot of bugs and plenty new features that ppl cry out for. so this bug has less to do with purist reasons, it's more along the lines of "i've got so many things to do that don't break the spec, they get priority".
Comment 130 Oded Arbel 2014-09-07 00:01:09 UTC
(In reply to comment #129)
> As far as I can tell, it is already clear that XKB specifications needs to
> be extended for this to be cleanly solved. While Ilya's hack works for many
> people, and as much as I would like to see this fixed, I understand why it
> is unacceptable to the developers.
...
> there's two-ish ppl working on input at them moment, both are badly
> overloaded because there's a lot of bugs and plenty new features that ppl
> cry out for. so this bug has less to do with purist reasons, it's more along
> the lines of "i've got so many things to do that don't break the spec, they
> get priority".

So I understand that this issue is currently not worked on by Xorg developers.

Priorities are a good thing, and I'm currently comfortable with the pragmatic approach of the downstream distributions applying Ilya's patch in their packages (which works fine for a lot of happy users who have reported as such - I have yet to hear a report where Ilya's patch is not improving behavior for multi-language users).

Still:

1) Its a good idea to have the pragmatic patch set maintained in this bug report - even if it will never be applied to upstream Xorg, simply as a central point for downstream distributors to get access to a reasonable workaround until a "correct" solution is available.

2) It will be a real shame if this issue, that is actively discussed by the community for 10 years now and is hurting a lot of users, will be ignored for another 10 years. In the mean time XKB2 - that was supposed to be the solution to all our problems - was relegated from "being worked on" to "being thought on" to "being dreamed of" (around 2010) and now appears to have fallen to the status of "it will never be important enough".
Comment 131 Adam Purkrt 2014-09-07 15:53:33 UTC
xkb should be extended to be able to recognize a sequence of key presses and key releases and fire action upon it. Again, this would be an extension, not a violation of current standard.

Currently, the group switching is defined in /usr/share/X11/xkb/symbols/group with parts like

partial modifier_keys
xkb_symbols "lalt_lshift_toggle" {
    virtual_modifiers Alt;
    key <LALT> {
        symbols[Group1] = [ NoSymbol, ISO_Next_Group ],
        virtualMods= Alt
    };
    key <LFSH> {
        type[Group1]="PC_ALT_LEVEL2",
        symbols[Group1] = [ Shift_L, ISO_Next_Group ]
    };
};

The following is what this part of the file would look like after appropiate changes in xkb code:

xkb_sequences "lalt_lshift_toggle" {
    sequence { keydown <LALT>, keydown <LFSH>, keyup <LFSH> } = ISO_Next_Group;
    sequence { keydown <LFSH>, keydown <LALT>, keyup <LALT> } = ISO_Next_Group;
}


For this to work
1) http://www.x.org/docs/XKB/XKBproto.pdf need to be extended with a small chapter
2) http://cgit.freedesktop.org/xorg/xserver/tree/xkb - code the run time check for sequences; changes to xkm format required
3) http://cgit.freedesktop.org/xorg/app/xkbcomp/tree/ - code the parsing of "xkb_sequences", "keydown", and "keyup" keywords


At least this is my impression after a day of investigation. I know this seems like unnecessarily big change compared to Ilya's patch. But, basically, that is what I mean by "clean solution". Unfortunatelly, it is more of a "dream solution", since I feel I will hardly be able to code this..
Comment 132 Andreas Wettstein 2014-09-07 17:38:19 UTC
Allowing arbitrary sequences to decide which action to take would certainly be powerful, but quite some effort, also for specification (think about multiple matching sequences).

In comment #117 I suggested an extension to the specification that is restricted to the enhancement request at hand.  But even this change would need a protocol bump. This is where this proposal is stuck.
Comment 133 Adam Purkrt 2014-09-10 19:44:22 UTC
Found partial workaround today.

It _is_ possible to setup xkb so that the group (i.e. layout) switch occurs on <Shift>+<Alt> (which means press and hold Shift, then press Alt - order matters) - and still <Alt>+<Shift>+<something> (first alt, then shift, then something) shortcuts work. All this without the need to recompile xserver.

Here's what I did:

$ setxkbmap us,cz
(just load the layouts I want to the server, switching not working yet)
$ xkbcomp $DISPLAY xkbdesc
(list the xkb description from server to a file named "xkbdesc")


Now two little changes to xkbdesc:

change1:

     key <LALT> {         [           Alt_L,          Meta_L ] };
to
     key <LALT> {         [           Alt_L,          ISO_Next_Group ] };


change2:

      key <RALT> {
          type[group1]= "TWO_LEVEL",
         type[group2]= "ONE_LEVEL",
         symbols[Group1]= [           Alt_R,          Meta_R ],
         symbols[Group2]= [ ISO_Level3_Shift ]
      };
to
      key <RALT> {
          type[group1]= "TWO_LEVEL",
         type[group2]= "TWO_LEVEL",
         symbols[Group1]= [           Alt_R,  ISO_Next_Group ],
         symbols[Group2]= [ ISO_Level3_Shift, ISO_Next_Group ]
      };


then
$ xkbcomp xkbdesc $DISPLAY
(load kbdesc to the server; ignore the warnings)

and voila! Shift+Alt (in that order) switches us<->cz keyboard and Alt+Shift+Tab works like it should.

I was actually quite surprised when I found this.

PS: Next time you start X, you can do just the last step, supposed you keep the xkbdesc file.
Comment 134 Adam Purkrt 2014-10-04 16:00:15 UTC
Perhaps easier variant of the above workaround pertaining Alt+Shift is to comment out the following (eight) lines in /usr/share/X11/xkb/symbols/group

first change (search for "lalt_lshift"):

partial modifier_keys
xkb_symbols "lalt_lshift_toggle" {
    virtual_modifiers Alt;
    key <LALT> {
        symbols[Group1] = [ NoSymbol, ISO_Next_Group ],
        virtualMods= Alt
    };
//    key <LFSH> {
//        type[Group1]="PC_ALT_LEVEL2",
//        symbols[Group1] = [ Shift_L, ISO_Next_Group ]
//    };
};



second change (~15 lines below):

partial modifier_keys
xkb_symbols "ralt_rshift_toggle" {
    virtual_modifiers Alt;
    key <RALT> {
        symbols[Group1] = [ NoSymbol, ISO_Next_Group ],
        virtualMods= Alt
    };
//    key <RTSH> {
//        type[Group1]="PC_ALT_LEVEL2",
//        symbols[Group1] = [ Shift_R, ISO_Next_Group ]
//    };
};




then load the keymap, in my case

$ setxkbmap us,cz -option grp:alt_shift_toggle

or set it through gui (Change layout option=Alt+Shift in XFCE), or just restart X server if you've already done so


Now <shift>+<left alt> (*in that order*, i.e. first press and hold any shift, then press left alt) switches keyboard layout

<alt>+<shift> (first alt, then shift) works as a modifier (i.e. shortcuts work), and does nothing in itself

<alt>+<shift>+<tab> works as it should


It would be nice to actually have a separate "rule" for this - titled "Shift+LAlt", available with -grp:shift_lalt_toggle, but unfortunatelly I don't know how to modify the rules files..
